The Ingersoll Rand spare parts refer to items such as Sensor, Controllers, Valves, pressure regulators, filters, oil and gas separator, lubricating oil, pipeline filter, automatic drain valve, Airend, bearings, shaft seals, shaft sleeves, gears, gear shafts, overhaul, Maintenance kits, Oil Coolers/heat exchangers, fan, radiator, Switch: pressure switch, temperature switch, emergency stop switch, differential pressure switch, transmission device: coupling, elastic body, plum blossom cushion, elastic block, gear, gear shaft, Hose: intake hose, high-pressure hose, Start plate: the contactor, thermal protection, reverse phase protector, line bar, relay, transformer, Cushioning parts: shock-absorbing pads, expansion joints, expansion valves, elastomers, plum blossom pads, elastic blocks, Meters: timer, temperature switch, temperature indicator, pressure gauge, decompression gauge, and motors.
Ingersoll Rand EPE/XFE/HPE/HXPE-250/300/350/400/450/500-2S Ultimate Spare Parts Catalog List 2022
Ingersoll Rand SSR 350-500 HP SPARE PARTS (Continued)
Panel Location Pins 39138490 On Base
Power On Light 39196225 On Starter Back Panel
Power On Light 39485032 On Intellisys Panel
Power On Light Bulb (24V) 39485024 In Intellisys
Emergency Stop Switch 39549167 On Intellisys Panel
Pressure Sensor (0-225) 39875539 On Starter Box (3APT, 4APT, 6APT, 5CPT)
Pressure Sensor (0-15) 39877618 On Starter Box (1AVPT)
Temperature Sensor 39560628 In Airend (2ATT)
Aftercooler (4ATT)
and Oil Piping (2CTT)
Temperature Sensor O-Ring 39404157 On Sensor
A. C. Line Filter 39201918 In Starter Box
Power Supply Board 39874425 In Starter Box
Intellisys 39875158 In Starter Box Door
Decal Kit 39244355 All Units
Stepper Motor 39566013 On Inlet Valve
Coupling Set, Stepper Motor 39495189 Stepper Motor to Inlet Valve
Nylon Tube, . 25” 39124813 Control Tubing
Hose 39143888 Blowdown Valve to Inlet Valve
Water Shutoff Solenoid Valve 39482757 Water Inlet Piping
Ingersoll Rand SSR 250-300 HP SPARE PA RT S
Maintenance Kit 250-300 HP 39676192 0 Maintenance Kit with Ultra Coolant
Ultra Coolant —(5 Gdlontainer) 39433735 7 Fill (33 Gallons)
Air Filter Element 39750732 1 At Airend Inlet
Coolant Filter Element 39911631 2 On Coolant Filter
Separator Element 39890660 1 In Separator Tank
Thermostatic Control
Valve Element 39437652 1 In Thermostatic Control Valve
Thermostatic Control Valve 39481429 1 Between Cooler & Oil Filter
Hose (With Pump Only) 39572334 1 Separator Tank to Oil Pump
Hose (With Pump Only) 39573092 2 Oil Pump to Thermo Valve
Hose 39572334 1 Separator Tank to Oilcooler
(Watercooled)Hose 39576723 1 Separator Tank to Oilcooler
(Aircooled)Hose 39572466 1 Thermostatic Valve to Oil Filter
(Aircooled)Hose 39572219 1 Thermostatic Valve to Oil Filter
(Watercooled) Hose 39572243 1 Blowdown Sol. Valve to Inlet Valve
Blowdown Solenoid Valve NEMA 39312897 1 To Inlet Valve (3SV)
Blowdown Solenoid Valve NEMA 39312905 1 To Inlet Valve (3SV)
Oil Stop Solenoid Valve NEMA 39318217 1 In Oil Filter Line (5SV)
Oil Stop Solenoid Valve NEMA 39318258 1 In Oil Filter Line (5SV)
Oil Stop Valve NEMA 39318225 1 In Oil Filter Line (5SV) (200 PSIG Unit Only)
Oil Stop Valve NEMA 39318266 1 In Oil Filter Line (5SV) (200 PSIG Unit Only)
Water Shutoff Solenoid Valve 39482757 1 Water-In Piping (Watercooled)
High Air Temperature Switch 39419668 1 In Airend (1ATS)
O-Ring 39404165 1 On HATS
Coolant Filt@P Switch 39246012 1 On Coolant Filter Mounting Bracket (1DPS)
Inlet Valve Assembly 42412155 1 Under Air Filter
Gasket 39486956 1 Under Inlet Valve
Gasket Isolation 9483169 4 Inlet Valve Mounting Bolts
Minimum Pressure Valve (XFE, EPE, HPE) 39477369 1 Tank Discharge Line
Minimum Pressure Valve (HXPE-200 PSIG) 39311824 1 Tank Discharge Line
O-Ring 95022372 1 Under Minimum Pressure Valve
Breather Filter 39112362 1 On Gearcase Wall
Dowel Pin 35332915 1 Gearcase to Airend
Dowel Pin 35295336 1 Gearcase to Airend
Dowel Pin 39194915 2 Gearcase to Motor
Shaft Seal 39493739 1 On Motor Shaft
Gasket 39405279 1 Under Seal Housing
Shaft Sleeve 39405287 1 On Motor Shaft
Gasket 39454558 1 Motor to Gearcase (440 Frame Series Motor)
Gasket 35782531 1 Motor to Gearcase (5000 Frame Series Motor)
O-Ring 39186002 1 Gearcase to Airend
Discharge Check Valve 39481361 1 Airend Discharge to
Separator Tank
Gaskets 39452354 2 Both Sides of CheckValve
Fan, 48”(Aircooled Only 60 Hz) 39850268 1 On Fan Motor Shaft
Fan, 42”(Aircooled Only 50 Hz) 39308572 1 On Fan Motor Shaft
Fan, 24”(Watercooled Only 60 Hz) 39197835 1 On Fan Motor Shaft
Fan, 24”(Watercooled Only 50 Hz) 39262811 1 On Fan Motor Shaft
Safety Valvei65 PSI 39225511 2 On Manifold
245 PSI (200 PSI Units Only) 39232145 2 On Manifold
Transformer Fuse (3.5 A) 39178736 2 In Starter Box (1FU)
Transformer Fuse (5.0 A) 39118484 1 In Starter Box (2FU)
Transformer Fuse (BBS-5. 0A) 39242458 1 In Starter Box (3FU)
B180-B110 Starter
Coil 39251368 2 In 180 Amp Contactor
Contact Kit 39251400 2 In 180 Amp Contactor
Coil 39251350 1 In 110 Amp Contactor
Contact Kit 39251392 1 In 110 Amp Contactor
Coil 39251376 2 In 250 Amp Contactor
Contact Kit 39251418 2 In 250 Amp Contactor
Coil 39251368 1 In 180 Amp Contactor
Contact Kit 3 9251400 1 In 180 Amp Contactor
Ingersoll Rand SSR 250-300 HP SPARE PARTS (Continued) QTY. LOCATION PART PER OR COMPRESSOR PART NO. UNIT USE B300-B180 Starter
Coil 39251376 2 In 300 Amp Contactor
Contact Kit 39251384 2 In 300 Amp Contactor
Coil 39251368 1 In 180 Amp Contactor
Contact Kit 39251400 1 In 180 Amp Contactor
Panel Location Pins 39138490 12 On Base
Power On Light 39196225 1 On Starter Back Panel
Power On Light 39485032 1 On Intellisys Panel
Power On Light Bulb (24V) 39485024 1 In Intellisys
Emergency Stop Switch 39549167 1 On Intellisys Panel
Pressure Sensor (0-225) 39875539 4 On Starter Box (3APT, 4APT, 6APT, 5CPT)
Pressure Sensor (0-15) 39877618 1 On Starter Box (1AVPT)
Temperature Sensor 39560628 3 In Airend (2ATT),
Aftercooler (4ATT) and Oil Piping (2CTT)
Temperature Sensor O-Ring 39404157 3 On Sensor
A. C. Line Filter 39201918 1 In Starter Box
Power Supply Board 39874425 1 In Starter Box
Intellisys 39875158 1 In Starter Box Door
Decal Kit 39244355 1 All Units
Stepper Motor 39566013 1 On Inlet Valve
Coupling Set, Stepper Motor 39495189 1 Stepper Motor to Inlet Valve
Nylon Tube, . 25” 39124813 * Control Tubing
Ingersoll Rand SSR 350-500 HP SPARE PARTS QTY. LOCATION PART PER OR COMPRESSOR PART NO. UNIT USE
Maintenance Kit 350-450 HP 39679287 0 Maintenance Kit with Ultra Coolant
Ultra Coolant — (5 Gal. Container) 39433735 8 Fill (86 Gallons)
Air Filter Element 39750732 1 At Airend Inlet
Coolant Filter Element 39911632 2 On Coolant Filter
Separator Element 39890678 1 In Separator Tank
Thermo Control Valve Element (35QIP) 39437652 1 In Thermo Control Valve
Thermo Control Valve Element (400-50QP) 39207402 1 In Thermo Control Valve
Thermo Control Valve (350 HP) 39481429 1 Between Cooler & Oil Filter
Thermo Control Valve (400-50QP) 39834684 1 Between Cooler & Oil Filter
Hose (With Pump Only) 39572334 1 Separator Tank to Oil Pump
Hose (With Pump Only) 39573092 1 Oil Pump to Thermo Valve
Hose 39572334 1 Thermo Valve to Oil Filter (W/C)
Hose 39572334 1 Thermo Valve to Oil Filter (A/C)
Hose (No-Pump) (W/C) 39572367 1 Separator Tank to Thermo Valve
Hose (No-Pump) (A/C) 39572276 1 Separator Tank to Thermo Valve
Blowdown Solenoid Valve NEMA 39312897 2 To Inlet Valve (3SV)
Blowdown Solenoid Valve NEMA 39312905 2 To Inlet Valve (3SV)
Oil Stop Solenoid Valve NEMA 39318217 1 In Oil Filter Line (5SV)
Oil Stop Solenoid Valve NEMA4 39318258 1 In Oil Filter Line (5SV)
Oil Stop Valve NEMA 39318225 1 In Oil Filter Line (5SV) (200 PSIG Units Only)
Oil Stop Valve NEMA 39318266 1 In Oil Filter Line (5SV) (200 PSIG Units Only)
Valve, Spring Check 39182696 1 In Oil Filter Out Line (With Oil Pump Only)
High Air Temperature Switch 39419668 1 In Airend (1ATS)
O-Ring 39404165 1 On HATS
Coolant FiltdP Switch 39246012 1 On Coolant Filter Mounting Bracket (IDPS)
Gasket 39486956 1 Under Inlet Valve
Minimum Pressure Valve 39801253 1 Tank Discharge Line
O-Ring 95060745 1 Under Minimum Pressure Valve
Breather Filter 39112362 1 On Gearcase Wall
Dowel Pin 35332915 1 Gearcase to Airend
Dowel Pin 35295336 1 Gearcase to Airend
Dowel Pin 39194915 2 Gearcase to Motor
Shaft Seal 39493739 1 On Motor Shaft
Gasket 39454558 1 Motor to Gearcase (440 Frame Series Motor)
Gasket 35782531 1 Motor to Gearcase (5000 FrameSeries Motor)
O-Ring 39186002 1 Gearcase to Airend
Discharge Check Valve 39481361 1 Airend Discharge to Separator Tank
Gaskets 39452354 2 Both Sides of CheckValve
Fan, 56”(Aircooled Only 60 Hz) 39918297 1 On Fan Motor Shaft
Fan, 56”(Aircooled Only 50 Hz) 39858865 1 On Fan Motor Shaft
Fan, 24”(Watercooled Only 60 Hz) 39197835 1 On Fan Motor Shaft
Fan, 24”(Watercooled Only 50 Hz) 39262811 1 On Fan Motor Shaft
Safety Valvel65 PSI 39225263 2 On Manifold
245 PSI (200 PSIUnit Only) 39232145 2 On Manifold
Transformer Fuse (3.5 A) 39178736 2 In Starter Box (1FU)
Transformer Fuse (5.0 A) 39118484 1 In Starter Box (2FU)
Transformer Fuse (BBS-5. 0A) 39242458 1 In Starter Box (3FU)
B250-B180 Starter
Coil 39251376 2 In 250 Amp Contactor
Contact Kit 39251418 2 In 250 Amp Contactor
Coil 39251368 1 In 180 Amp Contactor
Contact Kit 39251400 1 In 180 Amp Contactor
B300-B180 Starter
Coil 39251376 2 In 300 Amp Contactor
Contact Kit 39251384 2 In 300 Amp Contactor
Coil 39251368 1 In 180 Amp Contactor
Contact Kit 39251400 1 In 180 Amp Contactor
B300-B250 Starter
Coil 39251376 2 In 300 Amp Contactor
Contact Kit 39251384 2 In 300 Amp Contactor
Coil 39251376 1 In 250 Amp Contactor
Contact Kit 39251416 1 In 250 Amp Contactor
Ingersoll Rand INTELLISYS CONTROLLER AND STARTER BOX ASSEMBLY
39875158 ASSEMBLY, INTELLISYS CONTROLLER
39874375 GASKET
39128988 SCREW
95379392 WASHER, STAR
39485032 LIGHT, AMBER COMPLETE
39485024 BULB, 24V
39549167 SWITCH, EMERGENCY STOP
39877618 TRANSDUCER, 0-15 PSIG
39875570 CABLE, TRANSDUCER
39875539 TRANSDUCER, 0-225 PSIG
39875570 CABLE, TRANSDUCER
39461868 BULKHEAD CONNECTOR
(FOR MTG TRANSDUCER)
95922761 WASHER, STAR
39124813 X NYLON, TUBE
39497847 X TUBING, FLEXIBLE TEFLON LOW AMBIENT
39476221 CABLE, STEPPER MOTOR
39242367 PLUG, 2 POSITION
39204441 PLUG, 3 POSITION
39242375 PLUG, 10 POSITION
39186093 PLUG, 6 POSITION
39124813 X TUBING, NYLON NEMA 1 AND 4
39497847 X TUBING, FLEXIBLE TEFLON LOW AMBIENT
39124813 X TUBING, NYLON NEMA 1 AND 4
39497847 X TUBING, FLEXIBLE TEFLON LOW AMBIENT
39155478 ELBOW – NEMA 1 AND 4
39155478 ELBOW – NEMA 1 AND 4
39124813 TUBING, NYLON NEMA 1 AND 4
39497847 X TUBING, FLEXIBLE TEFLON LOW AMBIENT
54428537 BRACKET, TRANSDUCER
NO STARTER ASSEMBLY
39879580 BACK PANEL
39136486 TERMINAL BLOCK (STAR DELTA ONLY
35249721 SCREW
39190939 GROUND LUG
39141809 BOLT, GROUND LUG
39128541 NUT, GROUND LUG
39180898 BLOCK, 12 TERMINAL
35249721 SCREW
39165618 RELAY, BF-110/120V 50/60 HZ COIL
35249721 SCREW
39480504 FUSE BLOCK
35249721 SCREW
39113535 FUSE, 250V, 2 AMP
39245188 FUSE, 250V, BBS-6 AMP
39196225 LIGHT, POWER ON
35267202 BLOCK, 14 TERMINAL
35249721 SCREW
39201918 POWER FILTER
35249621 SCREW
39874425 POWER SUPPLY BOARD
39173810 STANDOFF
95929022 WASHER
39129994 SCREW
39242367 PLUG, 2 POSITION
39204441 PLUG, 3 POSITION
39186101 PLUG, 4 POSITION
39191630 PLUG, 5 POSITION
39553888 TRANSFORMER, 24V-130VA SIGNAL
35249721 SCREW
39125091 SOCKET, 11 BLADE (STAR DELTA)
39125091 SOCKET, 11 BLADE (FULL VOLTAGE)
39403290 RELAY, AUTO CONTROL STD (STAR DELTA)
39403290 RELAY, AUTO CONTROL STD (FULL VOLTAGE)
39125158 SCREW (STAR DELTA)、
39125158 SCREW (FULL VOLTAGE)
39164520 TERMINAL BLOCK
35249721 SCREW
STARTER (STAR DELTA) B180 – B110
54367628 BACK PANEL
39251046 CONTACTOR, 180 AMP
39251368 COIL, ASSEMBLY
39251400 KIT, CONTACT
39251160 CONTACTOR, AUXILIARY (N.O.)
39251152 CONTACTOR, AUXILIARY (N.O.)
39251103 RELAY, OVERLOAD
39251194 INTERLOCK, MECHANICAL
39251038 CONTACTOR, 110 AMP
39251350 COIL, CONTACTOR39251392 KIT, CONTACT
39251178 CONTACTOR, AUXILIARY (N.O., N.C.)
39203443 ARC SUPPRESSOR
39251442 TERMINAL LUG KIT
39164520 MOTOR TIE OFF BLOCK
39252903 BLOCK, TERMINAL
39252929 END SECTION
39252937 BLOCK, END STOP
39252945 JUMPER, 5-POLE
39251228 FAN MOTOR STARTER, 1.7 – 2.5A
39251285 CONTACTOR, AUXILIARY (N.O.)
39251244 FAN MOTOR STARTER, 4.1 – 6.3A
39251285 CONTACTOR, AUXILIARY (N.O.)
39251251 FAN MOTOR STARTER, 6.4 – 10A
39251285 CONTACTOR, AUXILIARY (N.O.)
39251269 FAN MOTOR STARTER, 10.1 – 16A
39251285 CONTACTOR, AUXILIARY (N.O.)
39251277 FAN MOTOR STARTER, 16.1 – 20A
39251285 CONTACTOR, AUXILIARY (N.O.)
39874425 ASSEMBLY, POWER SUPPLY
39173810 STANDOFF
39201918 FILTER, RFI
39196225 LIGHT, POWER ON
39480504 FUSE HOLDER, 2 POLE
39178736 FUSE, 600V, 3.5A (1FU)
39118484 FUSE, 250V, 5A (2FU)
39242458 FUSE, 600V, BBS-5A (3FU)
39318118 TRANSFORMER, 580VA, 50 HZ, 380, 415, 550V
39475983 TRANSFORMER, 580VA, 60HZ, 200, 230, 460, 575V
39485800 TRANSFORMER, 580VA, 380V-60HZ, 220V-50HZ
39190939 LUG, GROUND
39141809 BOLT, GROUND LUG
39128541 NUT, GROUND LUG
39141809 BOLT, GROUND LUG
39128541 NUT, GROUND LUG
Ingersoll Rand STARTER (STAR DELTA) B250-B180
54367628 BACK PANEL
39251053 CONTACTOR, 250 AMP
39251376 COIL, ASSEMBLY
39251418 KIT, CONTACT
39251160 CONTACTOR, AUXILIARY (N.O.)
39251152 CONTACTOR, AUXILIARY (N.O.)
39253158 RELAY, OVERLOAD
39251194 INTERLOCK, MECHANICAL
39251046 CONTACTOR, 180 AMP
39251368 COIL, CONTACTOR
39251400 KIT, CONTACT
39251178 CONTACTOR, AUXILIARY (N.O., N.C.)
39203443 ARC SUPPRESSOR
39251459 TERMINAL LUG KIT
39253174 CURRENT TRANSFORMER
39252903 BLOCK, TERMINAL
39252929 END SECTION
39252937 BLOCK, END STOP
39252945 JUMPER, 5-POLE
39251244 FAN MOTOR STARTER, 4.1 – 6.3A
39252887 FAN MOTOR STARTER, 19.1 – 32A
39251285 CONTACTOR, AUXILIARY (N.O.)
39924741 SWITCH, TRIP – USE WITH STARTER PART #39252887
39874425 ASSEMBLY, POWER SUPPLY
39173810 STANDOFF
39201918 FILTER, RFI
39196225 LIGHT, POWER ON
39480504 FUSE HOLDER, 2 POLE
39178736 FUSE, 600V, 3.5A (1FU)
39118484 FUSE, 250V, 5A (2FU)
39242458 FUSE, 600V, BBS-5A (3FU)
39318118 TRANSFORMER, 580VA, 50 HZ, 380, 415, 550V
39475983 TRANSFORMER, 580VA, 60HZ, 200, 230, 460, 575V
39485800 TRANSFORMER, 580VA, 380V-60HZ, 220V-50HZ
39190939 LUG, GROUND
39141809 BOLT, GROUND LUG
39128541 NUT, GROUND LUG
Ingersoll Rand STARTER (STAR DELTA) B300-B180
54367628 BACK PANEL
39252879 CONTACTOR, 300 AMP
39251376 COIL, ASSEMBLY
39251384 KIT, CONTACT
39251160 CONTACTOR, AUXILIARY (N.O.)
39251152 CONTACTOR, AUXILIARY (N.O.)
39253158 RELAY, OVERLOAD
39251194 INTERLOCK, MECHANICAL
39251046 CONTACTOR, 180 AMP
39251368 COIL, CONTACTOR
39251400 KIT, CONTACT
39251178 CONTACTOR, AUXILIARY (N.O., N.C.)
39203443 ARC SUPPRESSOR
39251459 TERMINAL LUG KIT
39253174 CURRENT TRANSFORMER
39252903 BLOCK, TERMINAL
39252929 END SECTION
39252937 BLOCK, END STOP
39252945 JUMPER, 5-POLE
39251244 FAN MOTOR STARTER, 4.1 – 6.3A
39252887 FAN MOTOR STARTER, 19.1 – 32A
39251285 CONTACTOR, AUXILIARY (N.O.)
39924741 SWITCH, TRIP – USE WITH STARTER PART #39252887
39874425 ASSEMBLY, POWER SUPPLY
39173810 STANDOFF
39201918 FILTER, RFI
39196225 LIGHT, POWER ON
39480504 FUSE HOLDER, 2 POLE
39178736 FUSE, 600V, 3.5A (1FU)
39118484 FUSE, 250V, 5A (2FU)
39242458 FUSE, 600V, BBS-5A (3FU)
39318118 TRANSFORMER, 580VA, 50 HZ, 380, 415, 550V
39475983 TRANSFORMER, 580VA, 60HZ, 200, 230, 460, 575V
39485800 RANSFORMER, 580VA, 380V-60HZ, 220V-50HZ
39190939 LUG, GROUND
39141809 BOLT, GROUND LUG
39128541 NUT, GROUND LUG
Ingersoll Rand STARTER (STAR DELTA) B300-B250
54367628 BACK PANEL
39252879 CONTACTOR, 300 AMP
39251376 COIL, ASSEMBLY
39251384 KIT, CONTACT
39251160 CONTACTOR, AUXILIARY (N.O.)
39251152 CONTACTOR, AUXILIARY (N.O.)
39253158 RELAY, OVERLOAD
39251194 NTERLOCK, MECHANICAL
39251053 ONTACTOR, 250 AMP
39251376 COIL, CONTACTOR
39251418 KIT, CONTACT
39251178 CONTACTOR, AUXILIARY (N.O., N.C.)
39203443 ARC SUPPRESSOR
39251459 TERMINAL LUG KIT
39253174 CURRENT TRANSFORMER
39252903 BLOCK, TERMINAL
39252929 END SECTION
39252937 BLOCK, END STOP
39252945 JUMPER, 5-POLE
39251244 FAN MOTOR STARTER, 4.1 – 6.3A
39252887 FAN MOTOR STARTER, 19.1 – 32A
39251285 CONTACTOR, AUXILIARY (N.O.)
39251244 USE WITH STARTER PART
39924758 CONTACTOR, AUXILIARY (N.O., N.C.)
39252887 USE WITH STARTER PART #
39924741 SWITCH, TRIP –
39252887 USE WITH STARTER PART #
39874425 ASSEMBLY, POWER SUPPLY
39173810 STANDOFF
39201918 FILTER, RFI
39196225 LIGHT, POWER ON
39480504 FUSE HOLDER, 2 POLE
39178736 FUSE, 600V, 3.5A (1FU)
39118484 FUSE, 250V, 5A (2FU)
39242458 FUSE, 600V, BBS-5A (3FU)
39318118 TRANSFORMER, 580VA, 50 HZ, 380, 415, 550V
39475983 TRANSFORMER, 580VA, 60HZ, 200, 230, 460, 575V
39485800 TRANSFORMER, 580VA, 380V-60HZ, 220V-50HZ
39190939 LUG, GROUND
39141809 BOLT, GROUND LUG
39128541 NUT, GROUND LUG
Ingersoll Rand 250-300 HP MAJOR COMPONENTS ASSEMBLY
39817804 TUBE, DISCHARGE (AIREND TO TANk)
39225511 VALVE, PRESSURE RELIEF 200 PSI(EPE, HPE, HXPE 250 & HXPE 300)
39232145 VALVE, PRESSURE RELIEF 245 PSI
39844725 TUBE, DISCHARGE (AIREND TO TANK) (200 PSIG UNITS ONLY)(XFE, EPE. HPE 300 & XFE 250)
95950341 BUSHING
95936233 BOLT, DISCHARGE VALVE TO AIREND
39879044 MANIFOLD
95935201 BOLT, DISCHARGE TO TANK 19A 39128566 4 NUT
95923363 NUT 20 39880745 1 SWITCH, PRESSURE NEMA 1
39452354 GASKET 39880984 1 SWITCH, PRESSURE NEMA 4
39481361 VALVE, DISCHARGE CHECK 21 39108949 1 NUT, LOCK SEALING NEMA 1 ONLY
39479860 GROUND STRAP 22 39108949 1 NUT, LOCK SEALING
39178678 BOLT, GROUND STRAP 23 95785192 1 NIPPLE
39824586 SUPPORT, MOTOR 24 39817788 1 SUPPORT, AIREND(440 FRAME SERIES MOTOR)
39481452 MOUNT, ISOLATION AIREND
39824594 SUPPORT, MOTOR 25A 39178678 8 SCREW, MOUNT TO BASE(5000 FRAME SERIES MOTOR) A 1 JUNCTION BOX, CONDUIT ASSEMBLY
39116330 SCREW, SUPPORT TO MOUNT
35252279 SCREW, JUNCTION BOX
95935201 BOLT, MOTOR TO SUPPORT
39823802 BASE, STANDARD
95923363 NUT
39825906 BASE, EXTENDED UNIT
woenenen DRIVE ASSEMBLY
39302336 MOUNT, VIBRATION
39419668 SWITCH, HIGH TEMPERATURE
39178678 BOLT, MOUNT TO BASE
GQ weenenne 1 AIREND ASSEMBLY
39116330 SCREW
95935201 BOLT, AIREND TO SUPPORT 290 wnennenn 1 TANK ASSEMBLY
95923363 NUT
39128509 SCREW, LEG TO TANK
39156435 CONNECTOR
39817739 LEG, TANK
V1 weeeenen 1 INLET ASSEMBLY
95694287 BOLT, LEG TO AIREND SUPPORT
39124813 TUBE, NYLON
95947651 WASHER
39155478 ELBOW, NYLON TUBING
95923355 NUT
95956249 CONNECTOR
39487426 GASKET
39572334 HOSE
35275494 HUB
39572466 HOSE (EXTENDED UNIT ONLY)
39156435 CONNECTOR
39124813 132” TUBE, NYLON
39194055 ELBOW
39111711 ADAPTER
Ingersoll Rand 350-500 HP MAJOR COMPONENTS ASSEMBLY
39816715 BASE, STANDARD
39124813 40” TUBE, NYLON
39302336 MOUNT, VIBRATION 15 weeeee= 1 INLET ASSEMBLY
39178678 BOLT, MOUNT TO BASE
39155478 ELBOW, NYLON TUBING
39116330 SCREW
39225263 VALVE, PRESSURE RELIEF 165 PSI
39817739 LEG, TANK 39232145 2 VALVE, PRESSURE RELIEF 245 PS!
95694287 BOLT, LEG TO AIREND SUPPORT (200 PSI UNIT ONLY)
95947651 WASHER
39816731 SUPPORT, AIREND
95923355 NUT 19 weeene– 1 CONDUIT ASSEMBLY (NEMA 1)
4 weene nee 1 TANK ASSEMBLY
39177357 SCREW, JUNCTION BOX
39128509 SCREW, LEG TO TANK
39585146 THERMISTOR
39816749 PIPE. DISCHARGE (VALVE TO TANK)
39207113 NOZZLE, OIL INJECTION (400-450HP)
95947644 BOLT, DISCHARGE VALVE TO AIREND
39303417 ELBOW, OIL INJECTION (400-450HP)
95934790 BOLT, DISCHARGE TO TANK
39854278 TUBE, OIL INJECTION (400-450HP)
95923363 NUT
39303409 MANIFOLD, OIL INJECTION (400-450HP)
39481361 VALVE, DISCHARGE CHECK
39114079 NUT
39481452 MOUNT, ISOLATION AIREND
39880745 SWITCH, PRESSURE NEMA 1
39178678 SCREW, MOUNT TO BASE
39880984 SWITCH, PRESSURE NEMA 4
39816780 SUPPORT, MOTOR
39108949 NUT, LOCK SEALING NEMA 1(440 FRAME SERIES MOTOR)
39108949 NUT, LOCK SEALING
39817077 SUPPORT, MOTOR 29 95785192 1 NIPPLE (5000 FRAME SERIES MOTOR)
35275494 HUB
39116330 SCREW, SUPPORT TO MOUNT
95950341 BUSHING (200 PSI UNITS ONLY)
95935201 BOLT, MOTOR AND AIREND TO SUPPORT
39879044 MANIFOLD
95923363 NUT
39128566 NUT
39419668 SWITCH, HIGH TEMPERATURE
39572367 HOSE
39153382 COUPLING
39572466 HOSE
39104054 NIPPLE
95937561 CONNECTOR
39131974 COUPLING
39452354 GASKET
39479860 GROUND STRAP
39156435 CONNECTOR
39178678 BOLT, GROUND STRAP
39124813 132” TUBE, NYLON
V1 weerennn 1 DRIVE ASSEMBLY
39194055 ELBOW
39156435 CONNECTOR
39111711 ADAPTER weeennee 1 AIREND ASSEMBLY
Ingersoll Rand 250-500 HP DRIVE TRAIN ASSEMBLY
1 x MOTOR
95934378 BOLT, GEARCASE TO MOTOR (440 FRAME SERIES MOTOR)
95934386 BOLT, GEARCASE TO MOTOR (5000 FRAME SERIES MOTOR)
95923363 NUT
39454558 GASKET, MOTOR TO GEARCASE (440 FRAME SERIES MOTOR)
782531 GASKET, MOTOR TO GEARCASE (5000 FRAME SERIES MOTOR)
39812615 GEARCASE
39179072 BOLT, GEARCASE TO ROTOR HOUSING
35332915 PIN, LOCATING DOWEL
39498522 PLUG
39186002 O-RING, FRONT HOUSING
39489836 RETAINER, GEAR FIRST STAGE
96700638 SCREW, ROTOR
39489844 RETAINER, GEAR SECOND STAGE
96700638
39497862
39497870
39489968
39489976
39101597
95929162
39405287
39405261
95929154 SCREW
39311519 SEAL, LIP
39405279 GASKET, SEAL HOUSING
35295336 PIN, DOWEL
39112362
39194915
39136304
39117734
95988002
95987996
Ingersoll Rand 250-500 HP AIREND WITH OIL PUMP
39176128 ELBOW, 45°
39199088 PUMP
35272533 BOLT, COVER
35516947 GASKET, PUMP
39499801 FLANGE, PUMP
95939930 BOLT, PUMP FLANGE
95028502 O-RING, PUMP FLANGE
39499645 MANIFOLD, PUMP
39822028 TUBE, PUMP BYPASS
95944435 CONNECTOR
39116512 VALVE, PUMP RELIEF
95937553 CONNECTOR
39481577 CONNECTOR
XXXXXXXX AIREND ASSEMBLY
XXXXXXXX DRIVE ASSEMBLY
39572334 HOSE
39836515 HOSE
39182696 VALVE. CHECK
95494019 CONNECTOR
39572334 HOSE
Ingersoll Rand 250-500 HP 8 INCH INLET VALVE WITH AIR FILTER ASSEMBLY STANDARD INLET
39320783 PLATE, INLET
96726880 BOLT
39320791 GASKET, INLET VALVE
39486956 GASKET, 8.00 INLET VALVE
39495965 SPACER, ISOLATION
39483169 GASKET, ISOLATION
95081618 WASHER
96715594 BOLT
39854153 BRACKET, AIR FILTER
39128467 SCREW
39854990 PLATE, BOTTOM AIR FILTER
39575345 PLATE, TOP AIR FILTER
39854237 SCREW, RETAINER
39311295 SCREW, RETAINER (HEAVY DUTY OPTION)
39305891 GASKET, AIR FILTER
39169594 SEALANT, GASKET ADHESIVE
(APPLY TO INLET VALVE GASKET
SURFACE)
39750732 ELEMENT, AIR FILTER
39873120 ELEMENT, AIR FILTER (HEAVY DUTY OPTION)
39195151 SEALING WASHER, RUBBER
95933313 WASHER, STEEL
42412155 ASSEMBLY, INLET VALVE
95938775 NUT, WING (HEAVY DUTY OPTION)
HOODED REMOTE INLET (OPTIONAL) REF. PART
NO. NUMBER QTY. DESCRIPTION
39320783 PLATE, INLET
96726880 BOLT
39320791 GASKET, INLET VALVE
39486956 GASKET, 8.00 INLET VALVE
39495965 SPACER, ISOLATION
39483169 GASKET, ISOLATION
95081618 WASHER
96715594 BOLT
39854153 BRACKET, AIR FILTER
39128467 SCREW
39863451 HOOD, AIR FILTER
39575345 PLATE, TOP AIR FILTER
39854237 SCREW, RETAINER
39854310 PLATE, HOOD COVER
39305891 GASKET, AIR FILTER
39169594 SEALANT, GASKET ADHESIVE
(APPLY TO INLET VALVE GASKET
SURFACE)
39750732 ELEMENT, AIR FILTER
39195151 SEALING WASHER, RUBBER
95933313 WASHER, STEEL
95938775 NUT, WING
42412155 ASSEMBLY, INLET VALVE
Ingersoll Rand 250 – 500 HP INLET VALVE/STEPPER MOTOR ASSEMBLY
42412148 VALVE, INLET 8.00
39495189 COUPLING, INLET VALVE
95229555 KEY
39306006 GASKET, STEPPER MOTOR
39566013 MOTOR, STEPPER
39128426 SCREW
39494869 GASKET, COUPLING COVER
39494877 COVER, COUPLING
39198809 SCREW
39564364 BOARD, PRINTED CIRCUIT
95073946 SCREW
39494851 ARM, INDICATOR
39128434 SCREW
39128541 NUT
39494836 GASKET, PRINTED CIRCUIT BOARD CAP
39823943 CAP, PRINTED CIRCUIT BOARD
39198809 SCREW
39300777 STOP, INLET VALVE
39404132 O-RING, VITON
39495395 GLAND, WIRE
95837233 FITTING, HYDRAULIC
95928214 PLUG, SOCKET
Ingersoll Rand 250-300 HP SEPARATOR TANK ASSEMBLY
39476916 SIGHT GLASS
39490230 ELBOW
39406996 O-RING, SIGHT GLASS
39545942 TUBE, OIL DELTA P
39478953 PLUG, OIL FILL
95937579 ADAPTER
42406025 TANK, SEPARATOR (ASME/CANADIAN)
39246012 WITCH, OIL DELTA
42406033 TANK, SEPARATOR (AUSTRALIAN)
39178827 SCREW
42406041 TANK, SEPARATOR 200PSI (ASME/CANADIAN)
39798004 SUPPORT, OIL FILTER
39155478 ELBOW
39128509 SCREW
95937694 ELBOW 26 SEE TABLE A 1 ORIFICE
39302039 VALVE, BALL
95937686 ELBOW
95947230 CAP
39259676 FILTER, OIL
39890660 ELEMENT, SEPARATOR
39128467 SCREW
39477369 VALVE, MINIMUM PRESSURE CHECK (XFE, EPE AND
39911631 ELEMENT, OIL FILTER
HPE UNITS) – SEE NOTE 2
39481460 ELBOW
39311824 VALVE, MINIMUM PRESSURE CHECK (HXPE UNITS –
39137518 HOSE
200 PSIG) – SEE NOTE
95220844 CLAMP, HOSE
39179403 STUD
39137542 CONNECTOR
95922910 NUT
95387361 PLUG
95022372 O-RING
39105739 VALVE, BALL TANK DRAIN
39152368 ELBOW
39477526 ELBOW
39802814 TUBE, BLOWDOWN
39140512 ELBOW
39572243 HOSE
39155478 PLUG
95937637 ELBOW
39829833 TUBE, OIL FILTER OUT
39312897 VALVE, BLOWDOWN NEMA 1 (165 PSIG)
39140512 ELBOW
39312905 VALVE, BLOWDOWN NEMA 4 (ALL 250-300HP)
39318217 VALVE, OIL STOP NEMA 1
95937538 ADAPTER
39318225 VALVE, OIL STOP NEMA 4
39111752 CONNECTOR
39318258 VALVE, OIL STOP NEMA 1
39417118 ADAPTER, SCAVENGE TUBE (200 PSIG UNIT ONLY)
39871702 TUBE, TANK SCAVENGE
39318266 VALVE, OIL STOP NEMA 4
39322748 ORIFICE, SCAVENGE (200 PSIG UNIT ONLY)
39847041 TUBE, SCAVENGE TO AIREND
54430830 MANIFOLD, IN AIREND
39195078 CLIP TUBE
95939971 TEE
39133145 SCREW
39124813 Xx TUBING, NYLON
39123898 HOSE, FLEX
39300900
39301999
39307939
Ingersoll Rand 350-500 HP SEPARATOR TANK ASSEMBLY
39476916 SIGHT GLASS
39246012 SWITCH, OIL DELTA P
39406996 O-RING, SIGHT GLASS 24A 39178827 1 SCREW
39478953 PLUG, OIL FILL
39798004 SUPPORT, OIL FILTER
42406066 TANK, SEPARATOR (ASME/CANADIAN)
39128509 SCREW, SUPPORT TO TANK
42406074 TANK, SEPARATOR (AUSTRALIAN) 26 SEE TABLE A 1 CONNECTOR, OIL FILTER OUT
42406082 ANK, SEPARATOR 200PSI (ASME/CANADIAN )
95937686 ELBOW
39155478 ELBOW
39259676 FILTER, OIL
95937694 ELBOW
39128467 CREW
95939971 TEE
39911631 ELEMENT, OIL FILTER
39124813 TUBING, NYLON
39481460 ELBOW
39123898 HOSE
39137518 HOSE
39890678 ELEMENT, SEPARATOR
95220844 CLAMP, HOSE
39801253 VALVE, MINIMUM PRESSURE CHECK
39137542 CONNECTOR
39179403 STUD
95387361 PLUG
95423687 NUT
39105739 VALVE, BALL TANK DRAIN
95060745 O-RING
39477526 ELBOW
95938171 ELBOW, TANK TO BLOWDOWN
39140512 ELBOW
39872643 TUBE, BLOWDOWN
39155478 ELBOW
39572243 HOSE
39829841 TUBE, OIL FILTER OUT
95937652 ELBOW, BLOWDOWN VALVE A
39318217 VALVE, OIL STOP NEMA 1
39312897 VALVE, BLOWDOWN NEMA
39318225 | VALVE, OIL STOP NEMA 4
39312905 VALVE, BLOWDOWN NEMA
39318258 VALVE, OIL STOP NEMA 1 (200 PSI UNIT)
95947636 TEE
39315266 VALVE, OIL STOP NEMA 4 (200 PSI UNIT)
39499744 MANIFOLD, BLOWDOWN
54430830 MANIFOLD, IN AIREND ( 350HP)
39417118 ADAPTER, SCAVENGE TUBE
54418066 MANIFOLD, OIL (400, 450, 500 HP WITH
39871694 TUBE, TANK SCAVENGE INTERSTAGE PIPING)
39322748 ORIFICE, SCAVENGE
39302039 VALVE, BALL
39841481 TUBE, SCAVENGE TO AIREND
95947230 CAP
39195078 CLIP, TUBE
95937538 CONNECTOR
39133145 SCREW
39490230 ELBOW
39545942 UBE, OIL DELTA P
95937579 ADAPTER
Ingersoll Rand 250-300 HP AIRCOOLED COOLER ASSEMBLY
39801725 OILCOOLER (150 PSI)
95941811 PLUG
39872304 OILCOOLER (200 PSI)
54393996 TUBE, SEPARATOR OUTLET
39133152 SCREW
39925532 GASKET
39803283 SUPPORT, RIGHT END TOP
95823365 SCREW
39133145 SCREW
95282257 FLANGE, 4.00 SCREWED
39822721 SUPPORT, OILCOOLER TOP
39452362 GASKET
39133145 SCREW
95934519 BOLT
39128632 CONNECTOR
95929188 LOCKWASHER
39482369 COVER, OIL-COOLER SUPPORT
39137518 TUBING
39133145 SCREW
39137542 CONNECTOR
39803317 SUPPORT, OILCOOLER SIDE
54421698 RAP, MOISTURE SEPARATOR
39133145 SCREW
39928577 SUPPORT, MOISTURE SEPARATOR
39481460 ELBOW
95079612 SCREW
39481429 VALVE, THERMO CONTROL
35108372 BOLT
39437652 ELEMENT, THERMO CONTROL VALVE
95928255 PLUG
39412127 O-RING, BODY
39560628 SENSOR, TEMPERATURE
95022257 O-RING, ELEMENT
39404157 O-RING
39848783 TUBE, THERMO VALVE TO TEE
39155478 ELBOW
39481502 UBE, OILCOOLER TO THERMO VALVE
39826011 TUBE, EXTENSION (EXT. PKG. ONLY)
39119219 ELBOW
39452362 GASKET, FLANGE 4.00
95929121 SCREW
95928958 BOLT
95923355 NUT
95234498 WASHER
39851050 BRACE, FAN MOTOR SUPPORT (60 HZ)
39116348 NUT
39858345 BRACE, FAN MOTOR SUPPORT (50 HZ)
39313127 TEE, SIDE OUTLET
39178678 SCREW
39572466 HOSE, 2.00 X 64.50
39850854 SUPPORT, FAN MOTOR (60 HZ)
39576723 HOSE, 2.00 X 75.00
39850557 SUPPORT, FAN MOTOR (50 HZ)
54397757 GUARD, FAN (60 HZ)
39178686 SCREW
54367370 GUARD, FAN (50 HZ)
39823968 ANGLE, SUPPORT
39133152 SCREW
39133145 SCREW
39817796 TUBE, MPCV-AFTERCOOLER
39850268 FAN, 48.00 (60 HZ)
95022349 O-RING, MPCV-DISCHARGE PIPE
39308572 FAN, 42.00 (50 HZ)
95930723 BOLT
54402441 PLATE, ORIFICE (60 HZ)
95929188 WASHER
54371935 PLATE, ORIFICE (50 HZ)
95929121 SCREW
39133145 SCREW
95923355 NUT
95929017 WASHER
39928544 AFTERCOOLER (150 PSI)
39803333 PLATE, EXHAUST BOTTOM
39928718 AFTERCOOLER (200 PSI)
39133145 SCREW
39452362 GASKET, 4.00 FLANGE
39822713 SUPPORT, OILCOOLER BOTTOM
39133152 SCREW
39133145 SCREW
95929188 LOCKWASHER
39803291 SUPPORT, RIGHT END BOTTOM
95934519 SCREW
39133145 SCREW
39891171 ELEMENT, MOISTURE SEPARATOR
54423280 ADAPTER, MOISTURE SEPARATOR TO TRAP
39487 434 GASKET, 3.50 INTERSTAGE
39928007 SHELL, MOISTURE SEPARATOR NOTE:
Ingersoll Rand 250-300 HP AIR DISCHARGE ASSEMBLY – NO AFTERCOOLER
39803804
39807383
39807482
39807375
39807466
39807730
39804372
39177183 U-BOLT
95929121 SCREW
39483250 FLANGE, 3.00 NPT PLATED
39454525 GASKET, FLANGE
95923355 LOCKNUT
39484431 BRACKET, PIPE SUPPORT
39128566 NUT
39133152 SCREW
95060018 O-RING, MPCV
39826193 PIPE, DISCHARGE
95929188 WASHER
95930723 BOLT
39124813 TUBING
39156393 ADAPTER
39560628 SENSOR, CABLE
39404157 O-RING
39479761 EE
Ingersoll Rand 350-500 HP AIRCOOLED COOLER ASSEMBLY
54390307 GUARD, FAN
39133152 SCREW
39821822 PLATE, BOTTOM EXHAUST
39133145 SCREW
39319728 LUG, NYLON BLACK
39812573 ANGLE, LOWER COOLER
39133145 SCREW
54402458 PLATE, LH ORIFICE
39133145 SCREW
39128632 CONNECTOR
39918297 FAN, 56.00 (60 HZ)
39858865 FAN, 56.00 (50 HZ)
39821855 SIDE, COOLER BOX REAR
39133145 SCREW
39804026 ANGLE, UPPER COOLER
39133145 SCREW
39801287 OILCOOLER
39178678 SCREW
39804018 ANGLE, UPPER ORIFICE
39133145 SCREW
54402466 PLATE, RH ORIFICE
39133145 SCREW
39821830 SIDE, COOLER BOX FRONT
39133145 SCREW
39493879 TUBE, OILCOOLER OUT-THERMO VALVE
39482369 COVER, OILCOOLER SUPPORT
39133145 SCREW
39481460 ELBOW – 350 HP UNITS
89140512 ELBOW – 400-500 HP UNITS
39834684 VALVE, THERMO VALVE – 400-500 HP UNITS
39207402 ELEMENT, THERMO VALVE – 400-500 HP UNITS
39481429 VALVE, THERMO VALVE – 350 HP UNITS
39437652 ELEMENT, THERMO VALVE – 350 HP UNITS
39481486 CONNECTOR – 350 HP UNITS
39128632 CONNECTOR – 400-500 HP UNITS
95928958 SCREW
39116348 NUT
95234498 WASHER
39812599 TUBE, 2.00 THERMO VALVE PORT B TO OILCOOLER INLET – 350 HP UNITS
39878491 TUBE, 2.00 THERMO VALVEPORT B TO OILCOOLER INLET – 400-500 HP UNITS
39481478 TEE
39572276 HOSE (WITHOUT PUMP)
39573092 HOSE (WITH PUMP ONLY)
39851225 SUPPORT, FAN MOTOR
39128517 BOLT
39851217 BRACE, FAN SUPPORT
39178678 SCREW
39572334 HOSE
39452362 GASKET, (EXTENDED PKG.)
39817051 TUBE, AFTERCOOLER (EXTENDED PKG.)
95929121 BOLT, (EXTENDED PKG.)
95923355 LOCKNUT (EXTENDED PKG.)
95934154 BOLT
95923355 LOCKNUT
39481593 FLANGE, SPLIT
39185442 BOLT
95929188 WASHER
95060018 O-RING
39452362 GASKET
39928692 AFTERCOOLER (150 PSI)
39928726 AFTERCOOLER (200 PSI)
39133145 SCREW
95929071 WASHER
39850318 ANGLE, BYPASS
39133145 SCREW
39850326 ANGLE, BYPASS
39133145 SCREW
39850300 ANGLE, BYPASS TOP
39133145 SCREW
39850334 ANGLE, BYPASS BOTTOM
39133145 SCREW
39891171 ELEMENT, MOISTURE SEPARATOR
39487434 GASKET, 3.50 INTERSTAGE
BSB SB 4a Ms a ap KH MOMABA WBA sBAKMOMHA AB RABRAAUARAWMOSBBAAUAKRNYDOOB
95934519 BOLT
95929188 LOCKWASHER
39928007 SHELL, MOISTURE SEPARATOR
95941811 PLUG
54393996 TUBE, SEPARATOR OUTLET
39925532 GASKET, 4.0
95823365 SCREW
95282257 FLANGE
39452362 GASKET, 4.0
95934519 BOLT
95929188 LOCKWASHER
54423280 ADAPTER, MOISTURE SEPARATOR TO TRAP
39137518 TUBING
39137542 CONNECTOR
54421698 TRAP, MOISTURE SEPARATOR
95928255 PLUG
39928577 SUPPORT, MOISTURE SEPARATOR
95079612 SCREW
35108372 BOLT
39560628 SENSOR-TEMPERATURE
39404157 O-RING
39155478 ELBOW
Ingersoll Rand 350-500 HP AIR DISCHARGE ASSEMBLY – NO AFTERCOOLER
39807375
39807466
39803911
39123864 COVER
39852553 PANEL, UPPER DISCHARGE,
39857834 FOAM, UPPER DISCHARGE PANEL
39128566 NUT
39810197 BRACKET, PIPE SUPPORT
39128483 SCREW
95060018 O-RING, MPCV
39124813 TUBING, NYLON
39156393 ADAPTER
39541677 SENSOR, CABLE
39404157 O-RING
39479761 TEE
95929188 WASHER
39185442 BOLT
39481593 FLANGE
39852561 PIPE, MPCV DISCHARGE
39116348 NUT
39483789 U-BOLT
39804703
Ingersoll Rand 250-300 HP WATERCOOLED ASSEMBLY
39804539 SUPPORT, COOLER
39482757 VALVE, WATER SHUTOFF SOLENOID
39178678 SCREW
39181177 NIPPLE
54380308 SUPPORT, ORIFICE
39482872 PLATE, COUPLING
39133145 SCREW
39133152 SCREW
39803861 AFTERCOOLER
95937561 CONNECTOR
39128509 SCREW
39824628 TUBE, OILCOOLER-WATEROUT
39116348 NUT
39804851 TUBE, AFTERCOOLER-OILCOOLER
54376678 GUARD, FAN
39572029 HOSE, 26″ WATERIN-AFTERCOOLER
39133152 SCREW
95946190 ELBOW, 45°
95929071 WASHER
54376660 SUPPORT, FAN MOTOR
39803853 OILCOOLER
39178678 SCREW
39128509 SCREW
39116348 NUT
39130828 BOLT
39805015 TUBE-THERMO VALVE TO OILCOOLER
39128558 NUT
95943023 TEE
39197835 FAN, 24″, 8 BLADE (60 HZ)
39481 460 ELBOW
39262811 FAN, 24″, 10 BLADE (50 HZ)
39481460 ELBOW
54421698 TRAP, MOISTURE SEPARATOR
39481429 VALVE, THERMO CONTROL
39137534 ELBOW
39437652 ELEMENT, THERMO CONTROL VALVE
39137518 TUBING
95022034 O-RING, BODY
39929567 SUPPORT, MOISTURE SEPARATOR
95022257 O-RING, ELEMENT 39930243 1 SUPPORT, MOISTURE SEPARATOR
39481486 CONNECTOR (EXTENDED UNITS)
39804943 TUBE, OILCOOLER TO THERMO VALVE
39133152 SCREW
39140512 ELBOW, W/O O-RING
95929071 WASHER
39483086 ELBOW (UNIT WITH CONTROL VALVE ONLY)
39929559 PLATE, MOISTURE SEPARATOR
39572334 HOSE, 2.00 X 48.00 LG – 150 PSI
39128483 SCREW
39224159 HOSE, 2.00 X 38.00 LG – 200 PSI
39128566 NUT
39572219 HOSE, 2.00 X 38.00 LG – 150 PSI
95916771 SCREW
39224167 HOSE, 2.00 X 70.00 LG – 200 PSI
39803333 PLATE, EXHAUST BOTTOM
95022349 O-RING 43 39818265 2 BRACE, SUPPORT COOLERS
39825732 PIPE, MPCV TO AFTERCOOLER
39178678 SCREW
95930723 BOLT
39155478 ELBOW
95929188 LOCKWASHER
39560628 SENSOR, TEMPERATURE
39452362 GASKET (PIPE TO AFTERCOOLER)
39404157 O-RING
95930723 BOLT
95928255 PLUG
39929666 TUBE, AFTERCOOLER TO MOISTURE
95494019 UNION
SEPARATOR
39824685 TUBE, WATER-OUT
39452362 GASKET
39558648 ANGLE, SUPPORT
95930723 BOLT
39133145 SCREW
39891171 ELEMENT, MOISTURE SEPARATOR
39541339 DECAL, WATER-IN
39487434 GASKET, 3.50 INTERSTAGE
95033627 PLUG
95934519 BOLT
39541321 DECAL, WATER-OUT
95929188 OCKWASHER
54423280 ADAPTER, MOISTURE SEPARATOR TO TRAP
39928007 SHELL, MOISTURE SEPARATOR
543893996 TUBE, SEPARATOR OUTLET
39925532 GASKET, 4.0 NOTES:
95823365 SCREW
39803275 SUPPORT, TOP R.T. END (EXAMPLE: 35A).
39178678 SCREW X – ORDER PER NUMBER OF INCHES REQUIRED.
95919114 ELBOW XX – FURNISH MOTOR PART NO. (STAMPED ON MOTOR NAMEPLATE) WHEN ORDERING REPLACE-OB QROR7R7A 4 FI ROW MENT
Ingersoll Rand 250 – 300 HP WATERCOOLED ASSEMBLY OPTIONS 90° WITH CONTROL VALVE And 90/115° NO AFTERCOOLER
39482872 Plate, Coupling
39482872 PLATE, COUPLING
39541339 Decal, Water In
39541339 DECAL, WATER IN
39181177 Nipple
39181177 NIPPLE
39482757 Valve, Water Shutoff
39482757 VALVE, WATER SHUTOFF
95937561 Connector
95937561 CONNECTOR
39541321 Decal, Water Out
39541321 DECAL, WATER OUT
95937678 Elbow
95937678 ELBOW
95919114 Elbow
95919114 ELBOW
39572029 Hose, 26″, Water In To Aftercooler
39807334 TUBE, WATER IN TO OILCOOLER
95946190 Elbow, 45°
95494019 UNION
39804851 Tube, Aftercooler To Oilcooler
39824685 TUBE, OILCOOLER TO WATER OUT
39824834 Tube, Oilcooler To Water Control Valve
39824628 TUBE, OILCOOLER TO CONTROL VALVE
39128632 Connector
39493242 Flange
95934519 Bolt 90/115° NO AFTERCOOLER WITH CONTROL VALVE
95922910 Locknut
95929188 Lockwasher REF. PART
39476452 Gasket, Flange NO. NUMBER QTY. DESCRIPTION
39185053 Valve, Water Control
39824628 Tube, Control Valve To Water Out
39128632 CONNECTOR
39493242 FLANGE
95934519 BOLT
95922910 LOCKNUT
95929188 LOCKWASHER
39476452 GASKET, FLANGE
39185053 VALVE, WATER CONTROL
39824628 TUBE, CONTROL VALVE TO WATER OUT
Ingersoll Rand 250 – 300 HP WATERCOOLED ASSEMBLY OPTIONS 115° WITH CONTROL VALVE 115° WITHOUT CONTROL VALVE
39482872 PLATE, COUPLING
39482872 PLATE, COUPLING
39541339 DECAL, WATER IN
39541339 DECAL, WATER IN
39181177 NIPPLE
39181177 NIPPLE
39482757 VALVE, WATER SHUTOFF
39482757 VALVE, WATER SHUTOFF
95937561 CONNECTOR
95937561 CONNECTOR
39541321 DECAL, WATER OUT
39541321 DECAL, WATER OUT
95937678 ELBOW
95937678 ELBOW
95919114 ELBOW
95919114 ELBOW
95645123 TEE
95645123 TEE
95946190 ELBOW, 45°
95946190 ELBOW, 45°
39482476 TEE
39119227 TEE
39824628 TUBE, OILCOOLER TO CONTROL VALVE
39824628 TUBE, OILCOOLER TO CONTROL VALVE
39128632 CONNECTOR
39824693 TUBE, CONTROL VALVE TO WATER OUT
39493242 FLANGE
39804901 TUBE, WATER IN TO OILCOOLER
95934519 BOLT
39804877 TUBE, WATER IN TO AFTERCOOLER
95922910 LOCKNUT
39824701 TUBE, AFTERCOOLER TO TEE OUT
95929188 LOCKWASHER
39495403 ELBOW
39476452 GASKET, FLANGE
95067203 VALVE, GLOBE
39185053 VALVE, WATER CONTROL
39181185 NIPPLE
39824628 TUBE, CONTROL VALVE TO WATER OUT
39181193 BUSHING
39804901 TUBE, WATER IN TO OILCOOLER
39804877 TUBE, WATER IN TO AFTERCOOLER
39824701 TUBE, AFTERCOOLER TO TEE OUT
39495403 ELBOW
95067203 VALVE, GLOBE
39181185 NIPPLE
39181193 BUSHING
Ingersoll Rand 300-500 WATERCOOLED ASSEMBLY – 90°
39481429 1 VALVE, THERMO – 350 HP UNITS
39437652 1 ELEMENT, THERMO VALVE – 350 HP UNITS
95022034 1 O-RING, BODY – 350 HP UNITS
95022257 1 O-RING, ELEMENT – 350 HP UNITS
39834684 1 VALVE, THERMO – 400-500 HP UNITS
39207402 1 ELEMENT, THERMO VALVE – 400-500 HP UNITS
39140512 1 ELBOW
39483086 1 ELBOW (UNIT WITH CONTROL VALVE ONLY)
39481460 2 ELBOW – 350 HP UNITS
39140512 2 ELBOW – 400-500 HP UNITS
39572334 1 HOSE (PORT “A” TO OIL FILTER)
39805494 1 TUBE, THERMO VALVE PORT “B” TO OILCOOLER INLET 350 HP UNITS
39878467 1 TUBE, THERMO VALVE PORT “B” TO OILCOOLER INLET 400-500 HP UNITS
39825666 PIPE, MPCV TO AFTERCOOLER
39481593 FLANGE, 4-BOLT SPLIT
95060018 O-RING
39185442 BOLT
95929188 WASHER
95943023 TEE
39572367 HOSE (TANK TO COOLER MANIFOLD)
39929666 TUBE, AFTERCOOLER TO MOISTURE SEPARATOR
95930723 BOLT
39560628 SENSOR, TEMPERATURE
39404157 O-RING
39155478 ELBOW
95941811 PLUG
39891171 ELEMENT, MOISTURE SEPARATOR
39487434 GASKET, 3.50 INTERSTAGE
95934519 BOLT
95929188 LOCKWASHER
39928007 SHELL, MOISTURE SEPARATOR
54393996 TUBE, SEPARATOR OUTLET
39925532 GASKET, 4.0
95823365 SCREW
95387361 PLUG
39929559 PLATE, MOISTURE SEPARATOR
39128483 SCREW
39128566 NUT
95916771 SCREW
39929278 SUPPORT, MOISTURE SEPARATOR
39133152 SCREW
95929071 WASHER
54423280 ADAPTER, MOISTURE SEPARATOR TO TRAP
54421698 TRAP, MOISTURE SEPARATOR
39137518 TUBING
39137534 ELBOW
REF. PART
NO. NUMBER QTY. DESCRIPTION
95033627 PLUG
39541339 DECAL, WATER IN
39569058 DECAL, WATER IN (SPANISH)
39854898 DECAL, WATER IN (PORTUGUESE)
39541321 DECAL, WATER OUT
39569066 DECAL, WATER OUT (SPANISH)
39854914 DECAL, WATER OUT (PORTUGUESE)
39804778 PLATE, BOTTOM EXHAUST
39801584 SCREW
39482872 PLATE, COUPLING
39133152 SCREW
95937561 CONNECTOR
39836457 TUBE, OILCOOLER OUTLET TO CONNECTOR
95494019 UNION39836432 1 TUBE, CONNECTOR TO BASE OUT
39805338 TUBE, AFTERCOOLER OUT TO OILCOOLER INLET
95937678 ELBOW
39801584 AFTERCOOLER
39128509 SCREW
39116348 NUT
54376660 SUPPORT, FAN MOTOR
39178678 SCREW
54380316 SUPPORT, ORIFICE
39133145 SCREW
54376678 GUARD, FAN
39133152 SCREW
95929071 WASHER
39812946 BRACE, WATER COOLER SUPPORT
39116330 BOLT
39116348 NUT
39804786 ANGLE, UPPER
39804752 SUPPORT, COOLERS
39178678 4 SCREW
39804745 1 OILCOOLER
39128509 4 SCREW
39116348 4 NUT
39197835 1 FAN, 24″, 8 BLADE (60 HZ)
39262811 1 FAN, 24″, 10 BLADE (50 HZ)
39130828 4 SCREW
39128558 4 NUT
39452362 2 GASKET, 4.00
95919114 1 ELBOW
39805346 1 TUBE, WATER VALVE TO AFTERCOOLER INLET
39482757 1 VALVE, WATER SHUTOFF SOLENOID
39479555 1 CONNECTOR, CONDUIT
39483060 1 TUBE, BASE IN TO WATER VALVE INLET
95928255 1 PLUG
39483201 1 TUBE, OILCOOLER TO THERMO VALVE PORT “C”
39481486 1 CONNECTOR – 350 HP UNITS NOTES:
39128632 1 CONNECTOR – 400-500 HP UNITS
Ingersoll Rand 350-500 HP WATERCOOLED ASSEMBLY – STAINLESS STEEL
39812946 2 BASE, COOLER SUPPORT
39116330 8 BOLT
39116348 8 NUT
54376678 2 GUARD, FAN
39133152 8 SCREW
39804752 1 SUPPORT, COOLER
39178678 4 SCREW
39197835 1 FAN, 24″ 8 BLADE
54380316 1 SUPPORT, ORIFICE
39133145 15 SCREW
39804786 1 ANGLE, UPPER
39130828 4 BOLT
39128558 4 NUT
54376660 1 SUPPORT, FAN MOTOR
39178678 4 SCREW
39128509 4 SCREW
39116348 4 NUT
39128509 4 SCREW
39116348 4 NUT
39452362 5 GASKET, FLANGE
95944344 2 ELBOW
95944351 3 CONNECTOR
95277802 1 UNION
39848007 1 TUBE, WATER OUT
39847967 1 TUBE, WATER IN
39306493 1 PLATE, COUPLING
39133152 4 SCREW
39821822 1 PLATE, EXHAUST BOTTOM
39133145 14 SCREW
39140512 1 ELBOW
39483201 1 TUBE, OILCOOLER TO THERMO VALVE
39481486 1 CONNECTOR – 350 HP UNITS
39128632 1 CONNECTOR – 400-500 HP UNITS
39481429 1 VALVE, THERMO – 350 HP UNITS
39437652 1 ELEMENT, THERMO VALVE – 350 HP UNITS
95022034 1 O-RING, BODY – 350 HP UNITS
95022257 1 O-RING, ELEMENT – 350 HP UNITS
39834684 1 VALVE, THERMO VALVE – 400-500 HP UNITS
39207402 1 ELEMENT, THERMO VALVE -400-500 HP UNITS
39481460 2 ELBOW – 350 HP UNITS
39140512 2 ELBOW – 400-500 HP UNITS
39805494 1 TUBE, THERMO VALVE PORT “B” TO OILCOOLER INLET – 350 HP UNITS
39878467 1 TUBE, THERMO VALVE PORT “B” TO OILCOOLER INLET – 400-500 HP UNITS
25 95943023 1 TEE
39572334 1 HOSE – PORT “A” TO OIL FILTER
95919114 1 ELBOW
39847983 1 TUBE, AFTERCOOLER – OILCOOLER
39847975 1 TUBE, WATER IN – AFTERCOOLER
39847991 1 TUBE, OILCOOLER – WATER OUT
95944369 1 ELBOW
39572367 1 HOSE, SEPARATOR TANK TO COOLER MANIFOLD
39825666 1 TUBE, MPCV TO AFTERCOOLER
39185442 16 BOLT
95929188 16 LOCKWASHER
39481593 2 FLANGE, 4-BOLT SPLIT
95060018 1 O-RING
39185442 BOLT
95929188 LOCKWASHER
39929666 TUBE, AFTERCOOLER TO MOISTURE SEPARATOR
95930723 BOLT
39560628 SENSOR, TEMPERATURE
39404157 O-RING
39155478 ELBOW
95941811 PLUG
95928255 PLUG
39891171 ELEMENT, MOISTURE SEPARATOR
39487434
95934519
95929188
39928007
54393996
39925532
95823365
95387361
39929559
39128483
39128566
95916771
39929278
39133152
95929071
54423280
54421698
39137518
39137534
Ingersoll Rand 350-500 HP WATERCOOLED ASSEMBLY – 115°
95033627 2 PLUG
39541339 1 DECAL, WATER IN
39569058 1 DECAL, WATER IN (SPANISH)
39854898 1 DECAL, WATER IN (PORTUGUESE)
39541321 1 DECAL, WATER OUT
39569066 1 DECAL, WATER OUT (SPANISH)
39854914 1 DECAL, WATER OUT (PORTUGUESE)
39804778 1 PLATE, EXHAUST
39133145 1 SCREW
39482872 1 PLATE, COUPLING
39133152 4 SCREW
95937678 3 ELBOW
95956249 1 CONNECTOR
95067211 1 VALVE, GLOBE
39805379 1 TUBE, AFTERCOOLER OUTLET TO GLOBE VALVE
95937561 2 CONNECTOR
39482997 1 TEE
39572367 1 HOSE, TEE-GLOBE VALVE TO BASE OUT
39836531 1 TUBE, TEE TO AFTERCOOLER INLET
39812946 2 BRACE, WATERCOOLER SUPPORT
39116330 8 BOLT
39116348 8 NUT
54380316 1 SUPPORT, ORIFICE
39133145 15 SCREW
39804752 1 SUPPORT, COOLER
39178678 4 SCREW
39804786 1 ANGLE, UPPER
54376678 2 GUARD, FAN
39133152 10 SCREW
39197835 1 FAN, 24″, 8 BLADE (60 HZ)
39262811 1 FAN, 24″, 10 BLADE (50 HZ)
39130828 4 SCREW
39128558 4 NUT
54376660 1 SUPPORT, FAN MOTOR
39178678 4 SCREW
39801576 1 OILCOOLER
39128509 4 SCREW
39116348 4 NUT
39801584 1 AFTERCOOLER
39128509 4 SCREW
39116348 4 NUT
95919114 1 ELBOW
95946190 1 ELBOW, 45°
39805460 1 TUBE, OILCOOLER OUT TO TEE
39836549 1 TUBE, TEE TO OILCOOLER INLET
95645123 1 TEE
39482757 1 VALVE, WATER SHUTOFF SOLENOID
39479555 1 CONNECTOR, DIN
39836515 1 TUBE, BASE IN TO WATER VALVE INLET
39483201 1 TUBE, OILCOOLER OUTLET TO THERMO VALVE PORT C
39481486 1 ADAPTER – 350 HP UNITS
39128632 1 ADAPTER – 400-500 HP UNITS
39481429 1 VALVE, THERMO -350 HP UNITS
39437652 1 ELEMENT, THERMO VALVE – 350 HP UNITS
95022034 1 O-RING, BODY – 350 HP UNITS
39834684 1 VALVE, THERMO – 400-500 HP UNITS
39207402 1 ELEMENT – THERMO VALVE – 400-500 HP UNITS
39805486 1 TUBE, THERMO VALVE PORT “B” TO OILCOOLER INLET – 350 HP UNITS
39878475 1 TUBE, THERMO VALVE PORT “B” TO OILCOOLER INLET – 400-500 HP UNITS
95943023 TEE
39140512 ELBOW
39483086 ELBOW (UNIT WITH CONTROL VALVE ONLY)
39481460 ELBOW – 350 HP UNITS
39140512 ELBOW – 400-500 HP UNITS
39572334 HOSE, PORT “A” TO OIL FILTER
39572367 HOSE, TANK TO COOLER MANFOLD
39825666 PIPE, MPCV TO AFTERCOOLER
95171864 SCREW
95929188 WASHER
39452362 GASKET
39481593 FLANGE, 4-BOLT SPLIT
95060018 O-RING
39185442 BOLT
95929188 WASHER
39929666 TUBE, AFTERCOOLER TO MOISTURE SEPARAT
95930723 BOLT
39452362 GASKET
39560628 SENSOR, TEMPERATURE
39404157 O-RING
39155478 ELBOW
95941811 PLUG
39929278 SUPPORT, MOISTURE SEPARATOR
39133152 SCREW
95929071 WASHER
39891171
39487434
39928007 SHELL, MOISTURE SEPARATOR
54393996 TUBE, SEPARATOR OUTLET
39925532 GASKET
95823365 SCREW
95387361 PLUG
39929559 PLATE, MOISTURE SEPARATOR
39128483 SCREW
39128566 NUT
95916771 SCREW
54423280 ADAPTER, MOISTURE SEPARATOR TO TRAP
54421698 TRAP, MOISTURE SEPARATOR
39137518 TUBING
39137534 ELBOW
95928255 PLUG
Ingersoll Rand 350-500 HP WATERCOOLED ASSEMBLY OPTIONS – 115° 115° WATERCOOLED WITH CONTROL VALVE and 115° WATERCOOLED NO AFTERCOOLER
39805379
39805429
39483011
95083556
39185053
39836598
39482872 1 PLATE, COUPLING 1 39482872 1 PLATE, COUPLING
39133152 4 SCREW 1A 39133152 4 SCREW
95937561 3 CONNECTOR 2 95937561 3 CONNECTOR
39836515 1 TUBE, SOLENOID VALVE INLET 3 39836515 1 TUBE, SOLENOID VALVE INLET
95937678 3 ELBOW 4 95937678 1 ELBOW
39482757 1 VALVE, WATER SHUTOFF SOLENOID 5 39482757 1 VALVE, WATER SHUTOFF SOLENOID
95645123 1 TEE 6 39836523 1 TUBE, OILCOOLER – WATER IN
39836549 1 TUBE, WATER IN – OILCOOLER 7 95919114 1 ELBOW
95919114 1 ELBOW 8 95946190 1 ELBOW, 45°
95946190 1 ELBOW, 45° 9 39572466 1 HOSE, OILCOOLER OUT TO WATER OUT
39805460 1 TUBE, OILCOOLER – WATER OUT
39482997 1 TEE
95067211 1 VALVE, GLOBE
95357737 2 CONNECTOR
39836531 TUBE, WATER IN – AFTERCOOLER
39119219
39805429
95357737
39483011
95083556
39185053
95937678
39836598
Ingersoll Rand 250-300 HP AIRCOOLED INTAKE ASSEMBLY
39804471 1 BATT, INTAKE FRONT
39803390 1 WALL, SILENCER
39133145 3 SCREW
39798616 6 RETAINER, BATT
39133145 12 SCREW
39803796 1 ANGLE, SUPPORT BATT
39133145 2 SCREW
39803804 1 SUPPORT, ANGLE BATT
39133145 2 SCREW
39865449 1 ANGLE, AFTERCOOLER UPPER
39133145 4 SCREW
39865472 1 PLATE, AFTERCOOLER BY-PASS
39133145 4 SCREW
39865464 2 ANGLE, AFTERCOOLER SUPPORT REAR
39133145 8 SCREW
39803655 4 ANGLE, AFTERCOOLER BOTTOM
39133145 11 SCREW
39804463 2 BATT, INTAKE BOTTOM
39803762 1 BATT, LARGE INTAKE
39803754 3 BRACE, BATT
39133145 6 SCREW
39803697 1 SUPPORT, BATT
39133145 2 SCREW
39865456 1 ANGLE, AFTERCOOLER LOWER
39133145 4 SCREW
Ingersoll Rand 350-500 HP AIRCOOLED INTAKE ASSEMBLY
39804729 2 BATT
39798616 6 RETAINER, BATT
39133145 12 SCREW
39801659 5 BRACE, ANGLE BATT
39133145 12 SCREW
39804711 1 BATT
39804067 1 SUPPORT, UPPER ANGLE
39133145 5 SCREW
39801675 2 SUPPORT, ANGLE BATT
39133145 4 SCREW
39801709 1 SUPPORT, ANGLE REAR
39133145 4 SCREW
39804737 1 BATT
39801717 1 WALL, SILENCER
39133145 3 SCREW
39812698 1 SUPPORT, AFTERCOOLER REAR BOTTOM
39133145 4 SCREW
39859103 1 SUPPORT, ANGLE BATT
39812821 1 ANGLE, FRONT
39930623 1 PLATE, INTAKE
39133145 3 SCREW
39930631 1 FOAM, INTAKE
39859087 1 COVER, INTAKE PLATE
39133145 4 SCREW
39930615 1 PANEL, INTAKE
39133145 6 SCREW
39859095 1 COVER, INTAKE PANEL AIRCOOLED (WITH AFTERCOOLER)
39133145 6 SCREW
39860036 1 COVER, INTAKE PANEL AIRCOOLED (WITH OUT AFTERCOOLER)
39133145 6 SCREW
Ingersoll Rand 250-300 HP ENCLOSURE ASSEMBLY
39803382
39133145
39821541
39133145
39803721
39133145
39814447
39803275
39803267
39803259
39803846
39803838
39133145
39482864
39133152
39803168
39803846
39803838
39133145
39138490
39495981
39133145
39803341
39133145
39814439
39928676
39928684
39178678
39803374
39133145
39803358
39133145
39821558
39133145
39803671
39133145
Ingersoll Rand 250-300 HP ENCLOSURE ASSEMBLY
39802913 PANEL, TOP LEFT
39804406
39142690
39256452
39803366
39804356
39142690
39256452
39802707
39804398
39142690
35256452
39802871
39803770
39929815
39930169
39802905
39804398
39142690
35256452
39803192
39133152
95929071
39803226
39803788
39142690
35256452
39133954
39803739
39804364
39133145
35256452
39929971
39930151
39142690
35256452
39930045
39133145
39807367
39807474
39133145
35256452
39803234
54400296
39133152
39803747
39804372
Ingersoll Rand 350-500 HP ENCLOSURE ASSEMBLY
39803887 1 ANGLE, LEFT END
39133145 4 SCREW
39803937 1 CORNER, LEFT REAR
39133145 4 SCREW
39812821 2 ANGLE, LEFT FRONT, RIGHT REAR
39833145 16 SCREW
39804620 3 SUPPORT, TOP
39133145 12 SCREW
39803945 6 SUPPORT, VERTICAL
39133145 12 SCREW
39810593 ANGLE, RIGHT FRONT, LEFT REAR
39133145 SCREW
39804026 ANGLE, UPPER
39133145 SCREW
39803986 CORNER, RIGHT REAR
39133145 SCREW
39804661 ANGLE, RIGHT END (EXHAUST)
39803994 FOAM, RIGHT CORNER
39133145 SCREW
39803978 CORNER, RIGHT FRONT
39133145 SCREW
39804661
39804091
39133145
39882196
39882204
39178678 SCREW
39803929 CORNER, LEFT FRONT
39133145 SCREW
39482864 COVER, (AIRCOOLED ONLY)
39833152 SCREW
39495981 COVER, FORKLIFT
39833145 SCREW
39138490 PIN, LOCATOR
Ingersoll Rand 350-500 HP ENCLOSURE ASSEMBLY
39803895 1 LOUVER, AIRCOOLED INTAKE 24 39801634 1 GRILL, EXHAUST
54399704 1 PANEL, WATERCOOLED INTAKE 24A 39133152 8 SCREW
95929071 8 WASHER, FLAT
39133152 8 SCREW
39804612 1 PANEL, STRIP RIGHT END
39804646 1 PANEL, TOP LEFT REAR
39142690 4 SCREW
39142690 5 SCREW
35256452 4 RECEPTACLE, CLIP ON
35256452 5 RECEPTACLE, CLIP ON
39804695 1 FOAM, RIGHT END STRIP PANEL
39808209 2 FOAM, TOP LEFT
39804638 1 PANEL, TOP LEFT FRONT
39804109 3 PANEL, TOP REAR
39142690 5 SCREW
39142690 12 SCREW
35256452 5 RECEPTACLE, CLIP ON
35256452 12 RECEPTACLE, CLIP ON
39808209 2 FOAM, TOP LEFT
39808191 3 FOAM, TOP FRONT/REAR
39803739 1 PANEL, UPPER FRONT
39810817 2 PANEL, STRIP FRONT/LEFT
39133145 4 SCREW
39133145 8 SCREW
39804364 1 FOAM, UPPER FRONT
39142690 6 SCREW
39804117 3 PANEL, TOP FRONT
35256452 6 RECEPTACLE, CLIP ON
39142690 12 SCREW
39810916 2 FOAM, STRIP FRONT/LEFT
35256452 12 RECEPTACLE, CLIP ON
39810445 2 PANEL, STRIP FRONT/RIGHT
39804364 1 FOAM, UPPER FRONT
39133145 8 SCREW
39133954 12 LATCH, DOOR
39142690 4 SCREW
39929260 1 PANEL, REAR WATERCOOLED
35256452 4 RECEPTACLE, CLIP ON
39930185 1 FOAM, REAR PANEL
39810908 2 FOAM, STRIP FRONT/RIGHT
39803366 3 PANEL, REAR/RIGHT END
39142690 6 SCREW
35256452 6 RECEPTACLE, CLIP ON
39804356 3 FOAM, REAR PANEL NOTE:
39802871 6 PANEL, COMMON (5 REQUIRED ON WATERCOOLED) FOAM AND STANDARD FASTENERS SUCH AS NUTS, BOLTS, AND SCREWS ARE LISTED AS SUB-
39142690 12 SCREW ITEMS (EXAMPLE: 174).
35256452 12 RECEPTACLE, CLIP ON
39803770 6 FOAM, COMMON (5 REQUIRED ON WATERCOOLED)
Ingersoll Rand 250-300 HP EXTENDED PACKAGE ENCLOSURE ASSEMBLY
39803382
39133145
39825955
39133145
39803721
39133145
39825963
39826102
39803267
39807680
39803838
39803846
39133145
39482864
39133152
39807672
39803838
39803846
39133145
39138490
39495981
39133145
39803341
39133145
39825948
39928676
39928684
39178678
39803374
39133145
39803358
39133145
39825930
39803671
39133145
Ingersoll Rand 250-300 HP EXTENDED PACKAGE ENCLOSURE ASSEMBLY
39807763 1 PANEL, TOP LEFT
39804406 1 FOAM, PANEL – TOP LEFT
39142690 8 SCREW
35256452 8 RECEPTACLE, CLIP ON
39807755 1 PANEL, LEFT REAR
39804356 1 FOAM
39142690 2 SCREW
35256452 2 RECEPTACLE, CLIP ON
39825922 3 PANEL, TOP
39826144 3 FOAM
39142690 24 SCREW
35256452 24 RECEPTACLE, CLIP ON
39825914 6 PANEL, EXTENDED (5 REQUIRED ON WATERCOOLED)
39826151 6 FOAM, EXTENDED PANEL (5 REQUIRED ON WATERCOOLED)
39803192 1 GRILL, EXHAUST
39133152 8 SCREW
95929071 8 WASHER
39803226 1 PANEL, LEFT END
39804356 1 FOAM
39133954 12 LATCH, DOOR
39807722 1 PANEL, UPPER FRONT
39804364 1 FOAM
39133145 4 SCREW
39929971 1 PANEL, AIR DISCHARGE, LOWER
39804372 1 FOAM
39142690 2 SCREW
35256452 2 RECEPTACLE, CLIP ON
39930045 1 PLATE, AIR DISCHARGE PANEL
39133145 4 SCREW
39807367 1 PANEL, AIR DISCHARGE, UPPER
39804380 1 FOAM
39133145 4 SCREW
39803234 1 LOUVER, AIRCOOLED
54400296 1 PANEL, LEFT END AIRCOOLED
39133152 8 SCREW
39930227 1 PANEL, REAR EXTENDED-WATERCOOLED
39804356 1 FOAM, REAR EXT. PANEL
39803747 1 PANEL, LEFT END-WATERCOOLED
39804372 1 FOAM, LEFT END PANEL
Ingersoll Rand 250 – 300 HP LOW AMBIENT ASSEMBLY
39483177 1 CONTROLLER, MODULATING MOTOR
39177357 2 SCREW
39181110 1 SET, WEATHERPROOF
39133145 2 SCREW
39181086 2 GROMMET, RUBBER
39576723 1 HOSE
39807706 1 PLATE, EXHAUST BOTTOM
39133145 18 SCREW
39119219 1 ELBOW
39481502 2 TUBE, OILCOOLER TO THERMO VALVE
39128632 2 CONNECTOR
39802079 1 COVER, ACCESS
39133145 12 SCREW
39481460 1 ELBOW
39491501 1 MOTOR, MODULATING DAMPER
39136783 2 JOINT, BALL
39189071 1 COVER, TRANSFORMER
39136759 1 CRANKARM, MOTOR
39140041 1 PUSHROD
39807680 1 CORNER, RIGHT REAR
39133145 18 SCREW
39807698 1 PANEL, RIGHT END
39133145 18 SCREW
39802046
39807672
39133145
39484332
39154323 WELL, CONTROL
39478193 VALVE, THERMOSTATIC CONTROL (250 HP)
39481429 VALVE, THERMOSTATIC CONTROL (300 HP)
39313127
39848783
39572466 HOSE
39482898 THERMOSTAT, AMBIENT SENSING
39133145 SCREW
54429618 PLATE, FAN ORIFICE
39184999 FAN, 48″ DIA.Aaamattaan nn igia
39103338 BUSHING, 1.875 SHAFT
Ingersoll Rand 250-300 HP LOW AMBIENT EXTENDED ENCLOSURE ASSEMBLY
39803382
39133145
39825955
39133145
39825963
39826102
39807680
39133145
39802079
39133145
39482864
39133152
39807698
39803341
39133145
39807672
39133145
39138490
39495981
39133145
39825948
39931381
39178678
39803374
39133145
39803358
39133145
39825930
39803671
39133145
39803721
39133145
Ingersoll Rand 250-300 HP LOW AMBIENT EXTENDED ENCLOSURE ASSEMBLY
39807763
39804406
39142690
35256452
39807755
39804356
39142690
35256452
39825922
39826144
39142690
35256452
39825914
39826151
39807409
39133152
39802046
39133954
39807722
39804364
39133145
39807730
39804372
39142690
35256452
39930045
39133145
39807748
39804380
39133145
39803234
39133152
Ingersoll Rand 250-300 HP OUTDOOR MODIFICATION ENCLOSURE
39803382
39133145
39821541
39133145
39803721
39133145
39803341
39133145
39814447
39803267
39803275
39482864
39133152
39803259
39133145
39803168
39138490
39495981
39133145
39814439
39928684
39178678
39803374
39133145
39803358
39133145
39821558
39133145
39803671
39133145
Ingersoll Rand 250 – 300 HP OUTDOOR MODIFICATION ENCLOSURE
39807763
39804406
39142690
39807755
39804356
39142690
39807771
39804398
39142690
39807714
39803770
39807789
39804398
39142690
39807409
39133152
39807417
39807391
39807490
39142690
39133954
39807722
39804364
39133145
39929971
39930151
39142690
39930045
39133145
39807367
39807474
39133145
39803234
39133152
39929815
39930169
39803747
39804372
Ingersoll Rand 350-500 HP LOW AMBIENT ASSEMBLY
54402458 PLATE, ORIFICE LEFT
54402466 PLATE, ORIFICE RIGHT
39483177 CONTROLLER, MOTOR
39133152 SCREW
39181110 SET, WEATHERPROOF
39482880 MOTOR, DAMPER MODULATING
39133152 SCREW
39817044 PANEL, BOTTOM EXHAUST
39802079 COVER, ACCESS MOTOR
39133152 SCREW
39812466 CORNER, RIGHT REAR
39802046 LOUVER, MODULATING
39133152 SCREW
39128434 SCREW
39128541 NUT
39812342 PANEL, STRIP RIGHT END
39133152 SCREW
39812458 CORNER, RIGHT FRONT
39484332 MANIFOLD – 350 HP UNITS
39319322 MANIFOLD – 400-500 HP UNITS
39482898 THERMOSTAT, AMBIENT SENSING
39133152 SCREW
39136759 CRANKARM, MOTOR
39140041 PUSHROD
39138839 CRANKARM, LOUVER
39136783 JOINT, BALL
39812573 ANGLE, LOWER OILCOOLER
39572466 HOSE
39181086 GROMMET, .88 RUBBER
39481429 VALVE, THERMO – 350 HP UNITS
39437652 ELEMENT, THERMO VALVE – 350 HP UNITS
39834684 VALVE, THERMO – 400-500 HP UNITS
39207402 ELEMENT, THERMO VALVE – 400-500 HP UNITS
39481460 ELBOW – 350 HP UNITS
39140512 ELBOW – 400-500 HP UNITS
39481486 CONNECTOR – 350 HP UNITS
39128632 CONNECTOR – 400-500 HP UNITS
39812599 TUBE, THERMO VALVE PORT “B” TO OILCOOLER INLET – 350 HP UNITS
39878699 TUBE, THERMO VALVE PORT “B” TO OILCOOLER INLET – 400-500 HP UNITS
Ingersoll Rand 350-450 HP EXTENDED PACKAGE ASSEMBLY
39826490 1 BASE, EXTENDED PACKAGE
39812789 2 PANEL, EXTENDED PACKAGE
39812888 2 FOAM, PANEL EXTENDED PACKAGE
39812813 1 PANEL, STRIP FRONT
39812896 2 FOAM, STRIP
39812912 1 ANGLE, FRONT RIGHT
39812797 1 TOP, FRONT
39812904 2 FOAM, TOP
39812920 1 PANEL, STRIP REAR
39812805 1 TOP, REAR WITH TROUGH
39812870 1 ANGLE, RIGHT REAR
Ingersoll Rand 350-500 HP OUTDOOR MODIFICATION ENCLOSURE
39803929
39133145
39803887
39133145
39803937
39133145
39812821
39133145
39804620
39133145
39803945
39133145
39810593
39133145
39804026
39133145
39803986
39804661
39133145
39803994
39133145
39138490
39803978
39804661
39133145
39495981
39133145
39928684
39178678
39804091
39133145
Ingersoll Rand 350-500 HP OUTDOOR MODIFICATION ENCLOSURE
39807201 1 LOUVER, EXHAUST 24A 39133145 8 Screw
39133152 8 SCREW 24B = 39142690 4 Screw
39807714 6 PANEL, COMMON FRONT/REAR
35256452 4 Receptacle, Clip On (5 REQUIRED ON 24D
39810908 2 Foam, Strip Front/Right WATERCOOLED)
39810825 2 Panel, Strip Front/Left
39803770 6 FOAM, COMMON FRONT/REAR
39133145 8 Screw (5 REQUIRED ON
39142690 6 Screw WATERCOOLED)
35256452 6 Receptacle, Clip On
39809728 1 PANEL, TOP LEFT FRONT
39810916 2 Foam, Strip Front/Left
39142690 5 SCREW
39807722 1 Panel, Upper Front
35256452 5 RECEPTACLE, CLIP ON
39133145 4 Screw
39808209 1 FOAM, TOP LEFT
39804364 1 Foam, Upper Front
39809710 1 PANEL, TOP LEFT REAR
39807755 | Panel, Rear
39142690 5 SCREW
39142690 2 Screw
35256452 5 RECEPTACLE, CLIP ON
35256452 2 Receptacle, Clip On
39808209 1 FOAM, TOP LEFT
39804356 1 Foam, Rear Panel
39809736 2 PANEL, TOP FRONT
39807193 1 Panel, Right End
39142690 8 SCREW
39133145 4 Screw
35256452 8 RECEPTACLE, CLIP ON
39133954 12 Latch, Door
39808191 2 FOAM, TOP FRONT/REAR
39803895 1 Louver, Aircooled Intake
39809744 2 PANEL, TOP REAR 54399704 1 Panel, Watercooled Intake (Not Shown)
39142690 8 SCREW
39133152 8 Screw
35256452 8 RECEPTACLE, CLIP ON
39929260 1 Panel, Rear-Watercooled Only
39808191 2 FOAM, TOP FRONT/REAR
39930185 1 Foam, Rear-Watercooled Only
39807151 1 PANEL, RIGHT FRONT TOP
39142690 5 SCREW
35256452 5 RECEPTACLE, CLIP ON NOTE:
39809751 1 FOAM, RIGHT TOP PANEL FOAM AND STANDARD FASTENERS SUCH AS NUTS, BOLTS, AND SCREWS ARE LISTED AS SUB-
39807185 1 PANEL, RIGHT REAR TOP ITEMS (EXAMPLE: 16A).
39142690 5 SCREW
35256452 5 RECEPTACLE, CLIP ON
39809751 1 FOAM, RIGHT TOP PANEL
39810809 2 PANEL, STRIP FRONT/RIGHT
O-RINGS Part Size/ Tube No. Thread ID Width Size
39404157 7/16-20 0. 351 0.072 1/4
39404132 9/16-18 0. 468 0. 078 3/8
39404165 3/4-16 0. 644 0. 087 1/2
39437074 7/8-14 0. 755 0. 097 5/8
39407531 1- 1/16-12 0.924 0. 116 3/4
39404173 1- 5/16-12 1.171 0. 116 1
39404140 1- 5/8-12 1.475 0.118 1-1/4
39406996 1- 7/8-12 1.720 0.118 1-1/2
39410279 2- 1/2-12 2.337 0.118 2
you are looking for Ingersoll Rand Spare Parts, no mater GENUINE ORIGINAL or OEM, or the great quality aftermarket spare parts, we get it covered and we will provide you the reliable solution soon. Just feel free to submit “RFQ” form below.
