Overview
Maintenance and replacement of Sullair air filter element:
The air filter element should be checked every day. Clean the dust bag and clean the dust cover every day. In a dusty environment, cleaning work should be more frequent.
Whenever the air filter element is clogged to indicate the red area, the filter element should be maintained; every 250 hours of work or 2 months, no matter who arrives first, check whether the air compartment is damaged and the air intake system is not tightly sealed; every 1500 work Hours or a year, no matter who appears first in both cases, the air filter element should be replaced.
Maintenance work can be carried out according to the following steps:
(1) Unscrew the bolts, take off the end cover, and take out the air compartment;
(2) The method of dust removal is: use compressed air to blow from the inside to the outside. The mouthpiece is about 10mm away from the inner surface of the filter element, from top to bottom along the circumference;
(3) In addition to dust removal, Sullair air filter maintenance should also be checked for damage. The method is to put a lighted bulb inside the filter element, and then carefully observe the outside to see if there is any light transmission;
(4) The service life of the air filter element is about 1000 hours. In dusty areas, the time to replace the air filter element should be shortened accordingly.
The engine needs to suck in a lot of air during the working process. If the air is not filtered, the dust suspended in the air is sucked into the cylinder, which will accelerate the wear of the piston assembly and the cylinder. Larger particles entering between the piston and the cylinder will cause serious “cylinder pull” phenomenon, which is especially serious in a dry and sandy working environment.
The air filter is installed in front of the carburetor or the air intake pipe to filter out dust and sand particles in the air and ensure that sufficient and clean air enters the cylinder.
Common Sullair Air Compressor Air Filter Part Numbers reference
040596
040899
047543
048463
049301
409853
409854
4051158
043334
042445
250028-034
250007-838
250007-839
250024-867
250018-652
02250135-149
88290007-018
02250127-684
88290004-372
02250044-537
02250046-012
02250046-013
02250131-499
02250131-498
02250125-371
02250125-372
02250131-498
88290002-337
88290002-338
88290001-469
88290003-111
88290003-730
88290001-466
88290001-467
02250135-150
If you can not find one air filter element for your Sullair air compressor, please send us the name plate and the spare parts numbers, we will get the right match soon.
Contact CPMC today to expect Genuine Sullair parts with competitive prices!
Unlike those middle handlers who sell Sullair air compressors parts on Alibaba.com, Aliexpress, or Globalsources, eBay, Amazon, etc, Chengdu Pudding Mechatronic Co.CPMC has our own professional website.This helps save a big burden for overseas buyers, because third party platform like Alibaba or eBay, Amazon, Globalsources, etc charges high commission fee and system maintenance fee to their online agent. Here with CPMC, we are confident to offer 5-10% cheaper than any purchase on Alibaba.
