Overview
This air end is for Industries Applicable below:
Automobile Shops, Cement Factory, Garment Shops, Building Material Shops, Food & Beverage Factory, Farms, Restaurant, Retail, Printing Shops, Construction works, Energy & Mining
Brand: Atlas Copco
Condition: New Warranty: 3-6 months – 1 Year
After Warranty Service: Video technical support, Online support, Spare parts
Machinery Test Report: Provided
Marketing Type: New Product 2020
Place of Origin: Wuxi, Jiangsu Province, China
Application: Atlas Copco Compressors
Part Number: 1616 7382 80, 1616 7382 90, 1616 7382 91
Package: Neutral Packing or wooden case packing
Delivery time: 7-45 Days (normally in one week time when with stock)
Feature: High Efficiency
COMPRESSOR DATA SHEET Rotary Compressor: Fixed Speed
MODEL DATA – FOR COMPRESSED AIR | |||
1 | Manufacturer: Atlas Copco | ||
2 |
Model Number: GA22-125 AP Date:
X Air-cooled Water-cooled Type: X Oil-injected Oil-free # of Stages: |
7/6/2018 | |
Screw | |||
1 | |||
3* |
Rated Capacity at Full Load Operating
Pressure a, e |
125.6 |
a,e acfm |
4 | Full Load Operating Pressure b | 125 | b
psig |
5 | Maximum Full Flow Operating Pressure c | 132 | c
psig |
6 | Drive MotorNominal Rating | 30 | hp |
7 | Drive Motor Nominal Efficiency | 91.7 | percent |
8 | Fan Motor Nominal Rating (if applicable) | 0.27 | hp |
9 | Fan Motor Nominal Efficiency | 77 | percent |
10* | e
Total Package Input Power at Zero Flow |
6.1 | kWe |
11 |
Total Package Input Power at Rated Capacity and Full Load Operating Pressure |
25.6 |
kW |
12* |
Specific Package Input Power at Rated Capacity and Full Load Operating Pressuree |
20.4 |
kW/100 cfme |
Local Service Location you can expect to get service: Australia, New Zealand, Bangladesh, Brazil, Canada, Chilie, Egypt, USA, United Kingdom,Germany,Italy,France,Viet Nam, Indonesia,Malaysia, Philippines, Peru, Saudi Arabia, Pakistan, India, Russia, Spain, Thailand, Morocco, South Korea, Chile, UAE, Colombia, Sri Lanka, Romania, South Africa, Kazakhstan, Ukraine, Kyrgyzstan, Tajikistan,Turkey and many more countries.
1. Using standard Atlas Copco profile (SAP), the rotor adopts 4/6 tooth combination, and the rotor diameter is equal. Compared with 5/6 tooth (Sigma) or 4/5 tooth (Cyclon) combination, the female rotor has higher rigidity , So it is not easy to deform, and the internal leakage loss is small.
2. SAP profile: due to compression force, it contacts the rear edge of the tooth side. The gap of the rotor seal line is small. The outlet hole at the exhaust end is small (small leak triangle). Small internal leakage and loss. Higher internal pressure ratio (10bar). Improved efficiency, especially in 10 and 13 bar models, which have larger rotor diameters and low tip-speeds.
3. Effective, reliable and long-life oil seals and gas seals after more than 40 years of continuous improvement and the test of time. It is composed of oil seal C with reverse thread and two stainless steel gas seal B. These oil seals and air seals maintain a small gap with the shaft but do not contact, and their sealing efficiency, reliability and life are far better than the general labyrinth seals or mechanical seals. A.C. There is a small leakage hole E between the oil seal and the gas seal, in case the seal is damaged, it can still provide compressed air.
4. Gearbox: It can reduce more energy consumption and costs. The axial force generated by the gear offsets the axial force acting on the male rotor. Direct drive does not have this advantage.
5.Keep the temperature lower.
Atlas Copco Compressor Air End Features:
1. Adopt 4/6 rotor tooth profile.
2. The gear box is specially designed to reduce the axial force. Using original imported SKF bearings to ensure service life.
Product advantages: original imported bearings to ensure the operating life of the host
Product parameters: profile line, using 4/6 teeth
Process flow:
Rotor milling
Disc cutter
CBN grinding wheel
CNC five-axis linkage rotor grinder
Atlas Copco Air End Maintenance Precautions:
1. Replace the special lubricating oil on time;
2. Regular main engine overhaul and maintenance to improve main engine efficiency;
3. Check whether the bearing coupling and other parts are in good condition before starting the new machine;
4. Pay attention to check the steering when starting up or changing cables.
Part Numbers List for Atlas Copco Genuine Air end for Screw Air Compressor
1616-7382-80
1616-7382-90
1616-7382-91
Our company provides Atlas air compressor and spare parts supply. If you need air filter, oil filter, oil and gas separator, special lubricating oil, coolant, air compressor cooler, pressure switch, intake valve, computer controller, pressure sensor, temperature sensor, temperature control valve, solenoid valve, Valve repair kits, hose assemblies, bearings, shaft oil seals, shaft sleeves, belts, couplings, head overhaul and maintenance kits, etc., we can provide competitive prices.
