Overview
The new G 2-7 will bring a new level of performance, comfort, efficiency and sustainability to your shop floor. Our smallest oil-injected rotary screw compressor gives you immediate benefits in 4 areas: duty cycle, cost of ownership, oil carry-over and noise level. We reinvented out smallest rotary screw compressor.
Atlas Copco Model G 2-7 – The Superior workshop Compressor
G 2-7 Features By the Numbers
G 2-7 range of oil-injected rotary screw compressors has the highlight features of being efficient, productive, quiet and clean.
5: An extremely low oil carry-over of 5 ppm helps protect your equipment and your products from oil contamination.
61: – The G 2-7 operates at 61-67 decibels, which makes it a safe and comfortable point-of-use companion. No sound attenuation or separate compressor room required.
24/7: – No need for cool-down periods because the G 2-7 can run around the clock.
46°C: – The G 2-7 can function reliably in ambient temperatures of up to 46°C.
Add it all up and you get an oil-injected rotary screw compressor that is unrivaled on the professional market.
What Makes the Atlas Copco G2-7 Oil Injected Rotary Screw Air Compressor the ideal ones?
- Plug-and-play, one-person installation.
- A premium-efficiency motor lowers energy use and costs.
- A low-vibration screw element minimizes noise to allow installation close to the point of use.
- Easy to operate thanks to its Elektronikon® Base controller.
- Service indications and visual alerts help ensure optimal working order.
- Choose between a floor- and a tank-mounted model. Different receiver sizes are available.
- A refrigerant dryer can be fully integrated for dry, quality air without taking up extra space.
- Prevent condensation at low loads and improve reliability with the optional oil heater.
Atlas Copco G2-7 Oil Injected Rotary Screw Air Compressor 50 Hz version Technical Data
bar(e) | psi | l/s | m3/h | cfm | kW | hp | dB(A) | Pack
Kg/ibs |
Full Feature
Kg/ibs |
|
G 2 | 8 | 116 | 6.1 | 22.0 | 12.9 | 2.2 | 3 | 61 | 165/364 | 190/419 |
10 | 145 | 4.9 | 17.6 | 10.4 | 2.2 | 3 | 61 | 165/364 | 190/419 | |
G 3 | 8 | 116 | 7.9 | 28.4 | 16.7 | 3 | 4 | 61 | 170/375 | 195/430 |
10 | 145 | 6.1 | 22.0 | 12.9 | 3 | 4 | 61 | 170/375 | 195/430 | |
G 4 | 8 | 116 | 10.0 | 36.0 | 21.2 | 4 | 5.5 | 62 | 175/386 | 200/441 |
10 | 145 | 8.6 | 31.0 | 18.2 | 4 | 5.5 | 62 | 175/386 | 200/441 | |
G 5 | 8 | 116 | 14.8 | 53.3 | 31.4 | 5.5 | 7.5 | 65 | 185/408 | 210/463 |
10 | 145 | 13.0 | 46.8 | 27.5 | 5.5 | 7.5 | 65 | 185/408 | 210/463 | |
G 7 | 8 | 116 | 17.7 | 63.7 | 37.5 | 7.5 | 10 | 67 | 195/430 | 225/496 |
10 | 145 | 16.4 | 59.0 | 34.7 | 7.5 | 10 | 67 | 195/430 | 225/496 |
Atlas Copco G2-7 Oil Injected Rotary Screw Air Compressor 60 Hz version |
||||||||||
bar(e) | psi | l/s | m3/h | cfm | kW | hp | dB(A) | Pack
Kg/ibs |
Full Feature
Kg/ibs |
|
G 2 | 8 | 116 | 6.2 | 22.3 | 13.1 | 2.2 | 3 | 61 | 180/397 | 205/452 |
10 | 145 | 4.6 | 16.6 | 9.7 | 2.2 | 3 | 61 | 180/397 | 205/452 | |
G 4 | 8 | 116 | 9.5 | 34.2 | 20.1 | 4 | 5.5 | 62 | 190/419 | 215/474 |
10 | 145 | 8.5 | 30.6 | 18.0 | 4 | 5.5 | 62 | 190/419 | 215/474 | |
G 5 | 8 | 116 | 13.8 | 49.7 | 29.2 | 5.5 | 7.5 | 65 | 200/441 | 225/496 |
10 | 145 | 12.3 | 44.3 | 26.1 | 5.5 | 7.5 | 65 | 200/441 | 225/496 | |
G 7 | 8 | 116 | 17.0 | 61.2 | 36.0 | 7.5 | 10 | 67 | 210/463 | 240/529 |
10 | 145 | 16.1 | 58.0 | 34.1 | 7.5 | 10 | 67 | 210/463 | 240/529 |
For G2-7 series models, single phase 230V 50 hz, and all models of 60 hz assembled in China, please send us inquiry before booking, we need to reconfirm the delivery leading time. Check out G2-7 detailed tech specifications and the Atlas Copco G2-22 range of models to learn more!
