Overview
Sullair pressure switch range adjustment method: Remove the cover of the pressure adjustment switch; select the maximum operating pressure through the pressure range adjustment screw. Turn counterclockwise to decrease the set value.
Sullair Pressure Switch Differential Pressure Adjustment
The pressure difference is the difference between the maximum operating pressure and the minimum operating pressure, and is generally set to 10 psig (0.7bar). Set extremely low operating pressure through the differential pressure adjusting screw. Turn counterclockwise to increase the pressure difference. After the pressure adjustment switch is adjusted, the pressure regulator must be adjusted to determine the pressure at which the air volume adjustment starts.
Attention Please!
The Sullair temperature switch stops the compressor when the exhaust temperature exceeds 235°F (113°C), and at the same time monitors the temperature of the oil and gas mixture discharged by the main engine; when the exhaust pressure exceeds the maximum value of P1, stops the compressor , And monitor the tank pressure at the same time, and determine whether the motor steering is correct through the tank pressure display.
Sullair temperature sensor & Sullair pressure sensor are important monitoring components of the air compressor control system. The thermal element on the temperature sensor & pressure sensor senses the temperature and pressure changes of the air compressor system, converts it into a 4-20mA standard current signal, and transmits it to the Sullair controller computer board (monitor) for display. At the same time, this The signal is compared and calculated with the set value in the monitor to determine whether to send an alarm signal. Whenever you suspect that the sensor is malfunctioning, use other standard instruments to measure the correctness (pressure, temperature, etc.). If the reading is not correct, first check the wire joints or pipe joints. If the connector is intact, replace the sensor and recalibrate it with a standard meter. The controller computer board is equipped with pressure sensor and temperature sensor calibration software. This calibration method can affect the offset of the pressure and temperature calculation, but does not affect the slope of the conversion curve. Because of this, the correct method is to heat or pressurize the sensor to its operating value. If this is too difficult, you can calibrate at room temperature/atmospheric pressure. Calibration can only be done when the machine is shut down and the external control is released.
Purchase with CPMC to expect Genuine Sullair Switch with better prices!
Unlike those middle handlers who sell Sullair air compressors parts on Alibaba.com, Aliexpress, or Globalsources, eBay, Amazon, etc, Chengdu Pudding Mechatronic Co.CPMC has our own professional website.This helps save a big burden for overseas buyers, because third party platform like Alibaba or eBay, Amazon, Globalsources, etc charges high commission fee and system maintenance fee to their online agent. Here with CPMC, we are confident to offer 5-10% cheaper than any purchase on Alibaba.
